Specifications
Brand Name :
Dajin
Model Number :
HTC-001
Certification :
Rosh/CE/IOS
Place of Origin :
China
MOQ :
500
Price :
3.84
Payment Terms :
L/C,T/T
Delivery Time :
25
Packaging Details :
21X21X21 cm
Wheel Diameter :
75 mm / 100 mm / 125 mm/ 150 mm
Tread Width :
37 mm
Bearing :
Double ball bearing
Load Height :
112mm / 139mm / 170mm / 193mm (by diameter)
Swivel Radius :
75mm / 85mm / 98mm / 115mm (by diameter)
Plate Size :
115*100 mm/100*80 mm/100*100 mm
Thread Size :
M12 × 30 mm
Load Capacity :
120kg (75mm) / 150kg (100mm) / 180kg (125mm) / 200kg (150mm)
Installation :
Top-plate mount
Wheel Material :
Polyurethane + polypropylene core
Description
Polyurethane Medium-Heavy Duty Casters
Features

1.High-Performance TPR Tread: 37mm wide thermoplastic rubber offers superior shock absorption and floor protection

2.Reinforced Load Capacity: Supports 110-180kg per caster (varies by wheel diameter) for medium-heavy applications

3.Premium Bearing System: Steel double ball bearings ensure smooth 360° rotation with minimal effort

4.Durable Construction: Combination of TPR tread and polypropylene core provides excellent wear resistance

5.Versatile Sizing: Available in 75/100/125/150mm diameters to match different equipment needs

Function
These casters combine high load capacity with precise maneuverability. The polyurethane tread offers superior shock absorption and quiet operation, while the double ball bearing system guarantees consistent performance even with frequent heavy use. Ideal for equipment requiring both mobility and stability.
Application

1.Industrial Equipment: Machinery movers, assembly line carts

2.Medical Transport: Hospital beds, medication dispensing carts

3.Food Industry: Bakery racks, kitchen utility carts

4.Retail Environments: Heavy display units, promotional stands

5.Warehouse Operations: Medium-duty platform trucks, service carts

Technical Parameters

item
value
Model Name
 Polyurethane Medium-Heavy Duty Casters
Tread Polyurethane
Center
Polypropylene
Type
Plate Casters, Stem Casters, Bolt-Hole Casters, Side-Mount Casters
Style
Rigid, SWIVEL, Swivel & Rigid
Customized support
OEM, ODM, OBM
Place of Origin
China
Wheel Diameter 75mm / 100mm / 125mm / 150mm
Bearing
double ball bearing
Thread Size M12 × 30 mm
Load Capacity
 120kg (75mm) / 150kg (100mm) / 180kg (125mm) / 200kg (150mm)
Load Height
112mm / 139mm / 170mm / 193mm
