EDL Equipment Casters 3Inch PA E-coated Casters With Brake 500Kg RoadM433-16S
EDL Equipment Casters 3Inch PA E-coated Casters With Brake 500Kg RoadM433-16S
EDL Equipment Casters 3Inch PA E-coated Casters With Brake 500Kg RoadM433-16S
EDL Equipment Casters 3Inch PA E-coated Casters With Brake 500Kg RoadM433-16S
EDL Equipment Casters 3Inch PA E-coated Casters With Brake 500Kg RoadM433-16S
EDL Equipment Casters 3Inch PA E-coated Casters With Brake 500Kg RoadM433-16S
EDL Equipment Casters 3Inch PA E-coated Casters With Brake 500Kg RoadM433-16S
EDL Equipment Casters 3Inch PA E-coated Casters With Brake 500Kg RoadM433-16S
EDL Equipment Casters 3Inch PA E-coated Casters With Brake 500Kg RoadM433-16S
EDL Equipment Casters 3Inch PA E-coated Casters With Brake 500Kg RoadM433-16S
Specifications
Brand Name :
EDL
Model Number :
M433-16S
Certification :
ISO9001, ISO14001, RoHS
Place of Origin :
China
MOQ :
1pcs
Price :
Negotiate
Payment Terms :
T/T
Supply Ability :
30,000pcs/day
Delivery Time :
3-15days
Packaging Details :
Carton
Name :
Equipment Casters
Wheel Diameter :
3inch(75mm)
Tread Material :
PA
Mounting Type :
Threaded Swivel/Brake
Dynamic Load :
500kg
Mounting Height :
100mm
Frame Material :
Cold-Rolled Plate
Threaded Size :
M16*25
Bracket Thickness :
3mm
Surface Treatment :
Electrophoretic
Bracket Width :
46mm
Wheel width :
40mm
Bearing :
Double ball bearings
Tread Color :
Black
Applicable Temperature :
-20℃～100℃
Tread Hardness :
67D
Description

EDL Equipment Casters 3Inch PA E-coated Casters With Brake 500Kg RoadM433-16S

The EDL Equipment Caster M433-16S is a 3-inch threaded-stem industrial caster designed to deliver exceptional strength, stability, and wear resistance for heavy-duty equipment. Available in swivel and brake versions, it offers smooth maneuverability and firm locking control, making it a dependable choice for industrial machinery, production systems, and automation setups.

This caster is equipped with a durable PA (nylon) wheel, engineered for high hardness and abrasion resistance, ensuring a long service life even under continuous operation. With a hardness rating of 67D, it provides excellent load-bearing capability and minimal deformation under pressure. Each unit supports up to 500 kg, maintaining stable performance on a variety of surfaces.

The E-coated steel bracket adds a protective layer against corrosion and oxidation, extending the caster’s operational life in demanding environments. Capable of working reliably within a temperature range of -20°C to 100°C, it performs well in both low- and high-temperature conditions.

Combining robust construction, reliable braking, and smooth motion, the EDL M433-16S offers a versatile mobility solution for industrial and mechanical equipment that requires both durability and precision handling.

Wheel ltem No.Instruction

Wheel

Item No.

 Size

Wheel

Diameter

Wheel

Width

Bracket

Width

Load

Capacity

 Core Tread Bearing

Applicable

Temperature

 Hardness
M433-16 3" 75mm 40mm 46mm 500Kg /

PA

Double ball

bearing 6001

 -20℃～100℃ 67D

EDL Equipment Casters 3Inch PA E-coated Casters With Brake 500Kg RoadM433-16SEDL Equipment Casters 3Inch PA E-coated Casters With Brake 500Kg RoadM433-16S

EDL Equipment Casters 3Inch PA E-coated Casters With Brake 500Kg RoadM433-16SEDL Equipment Casters 3Inch PA E-coated Casters With Brake 500Kg RoadM433-16S

EDL Equipment Casters 3Inch PA E-coated Casters With Brake 500Kg RoadM433-16S

FAQ:

Q: Are you manufacturer or trading company?
A: We are caster wheels manufacturer since 1987.

Q: Where is your factory? Can I visit ?
A: Our factory is at Taizhou, Zhejiang, China. 2 hours by car from Yiwu. Welcome to visit.

Q: What is your delivery time?
A: Normally within 1 week. It's up to the order quantity.

Q: What is the term of payment?
A: Payment terms: 30%(it's stand product, for customized product it's 50%) of deposit upon signing the PI and the rest will be cleared by T/T before delivery.

Q: Are samples available?
A: Yes, sample is fine at any time, negotiable.
