IFM Pressure Vacuum Sensor IP67 Hydraulic Pneumatic Automation IFM Sensor
IFM Pressure Vacuum Sensor IP67 Hydraulic Pneumatic Automation IFM Sensor
Specifications
Model Number :
PN/PE、PT/PU、PI、PM、PL 、PY、PG24 、PQ、PV、
Certification :
CE、UL 、EMC、IP67/IP69K
Place of Origin :
Germany
MOQ :
1
Price :
$8-$1500
Payment Terms :
L/C,D/P,D/A,T/T,Western Union
Delivery Time :
3-5Workday
Type :
Industrial Sensors And Controls
Warranty :
Original Manufacturer's Warranty
Pakage :
Original Pakage
Shipping Term :
International Express（DHL/FEDEX/TNT/UPS/ARAMEX）/Sea Freight / Air Freight / International Special Line
Freight Charge :
For Industrial Equipment (E.G., PLC Modules, Inverters..), Shipping Cost Varies By Package Weight/Volume And Delivery Location. Contact Our Sales Team For A Customized Shipping Solution And Quote
Description
High Precision Pressure Vacuum Sensor with IP67 Protection and IO-Link for Hydraulic Pneumatic Automation
Pressure Vacuum Sensor delivers high precision measurement with IP67 robust protection and IO-Link communication for smart industrial connectivity. It ensures stable and reliable pressure and vacuum monitoring, perfectly adapted to hydraulic systems, pneumatic equipment, and automated production lines in various harsh industrial environments.
Product Highlights
  • High-precision measurement, low drift, stable reading for pressure & vacuum monitoring
  • IP67 waterproof & dustproof, reliable operation in harsh industrial environments
  • Built-in IO-Link V1.1, supports remote parameter setup & real-time data diagnosis
  • Robust anti-vibration & anti-interference, stable output under long-term working
  • Wide compatibility for hydraulic, pneumatic systems & automated production lines
  • Durable stainless steel/ceramic sensing element, long service life, maintenance-free
Technical Specifications
Sensor Series Full Models Measuring Range Accuracy Protection Class Communication Interface Medium Temperature Key Parameters Adapted Industries
PN/PE (Industrial Universal with Display) PN2094, PN2098, PN7293, PN3129, PN016A, PE7006, PE3009, PE3029, PE7002, PE7004 PN2094: -1…10 bar; PN2098: -1…100 bar; Others: -1…25 bar to -1…600 bar ±0.3% FS IP67 IO-Link V1.1, 4-20mA/0-10V -25…80°C Ceramic capacitor element, G1/4 process connection, LED digital display, anti-vibration and anti-interference General industry, hydraulic & pneumatic systems, automated production lines
PT/PU (Mini Industrial) PT5402, PU5402, PT9554, PT3543, PT9542 0…100 bar to 0…600 bar ±0.5% FS IP67 Analog output + IO-Link -25…85°C Compact design, stainless steel housing, standard M12 connector Pneumatic systems, small hydraulic equipment, electronic manufacturing
PI (Hygienic with Digital Display) PI2894, PI7993, PI2793, PI2799 -1…10 bar to -1…25 bar ±0.2% FS IP69K IO-Link -25…135°C Flush diaphragm design, stainless steel 316L, resistant to high-temperature and high-pressure cleaning Food & beverage, pharmaceutical, CIP/SIP processes
PM (Hygienic with Analog Output) PM1605, PM1643 -1…10 bar to -1…100 bar ±0.3% FS IP69K IO-Link + 4-20mA -25…150°C Ceramic measuring element, resistant to viscous media/particles, burst pressure 400 bar Food & beverage, dairy products, hygienic fluid monitoring
PL (Industrial Flush-Mounted) PL1502, PL1503, PL1504, PL1506, PL1507, PL1512, PL1514, PL1515, PL5400, PL5401, PL5402 -1…6 bar to 0…250 bar ±0.3% FS IP67 Analog output -20…125°C Full metal housing, G1/4/G1/2 process connection, strong overload resistance Heavy-duty hydraulics, construction machinery, metallurgy
PY (Homogenizer-Specific) PY2033, PY9961, PY7000, PY9294 -1…25 bar ±0.3% FS IP67 IO-Link + Switching output -20…125°C Dual output, resistant to pulse pressure, suitable for high-pressure homogenization processes Pharmaceutical, food processing, chemical homogenization equipment
PG24 (Industrial High-Precision with Display) PG2409, PG2789, PG2793, PG2889, PG2897, PG2898 -1…25 bar to -1…600 bar ±0.3% FS IP67 IO-Link, 4-20mA/0-10V -25…80°C Dual display (digital + analog), scalable measuring range, high precision Precision manufacturing, testing equipment, automated inspection lines
PQ (Vacuum/Compressed Air-Specific) PQ7834, PQ3834, PQ7809, PQ3809, PQ0834, PQ0809 -1…1 bar, -1…10 bar ±0.3% FS IP67/IP65 IO-Link, 4-20mA, Switching output -25…80°C Compact design, dual-color LED display, G1/8 process connection, moisture-proof silicon measuring unit Vacuum systems, compressed air monitoring, pneumatic control
PV (Switch Type with Monitoring) PV7001, PV7002, PV7003, PV7004, PV7005 0…250 bar to 0…600 bar ±0.5% FS IP67/IP69K IO-Link + Switching output -25…80°C Software-configurable switching points, stainless steel housing, G1/4 process connection, corrosion-resistant Chemical industry, petroleum, industrial fluid control
Product Selection Notes
  1. Range Coverage: The full series supports -1…600 bar, covering vacuum to high-pressure scenarios. Interfaces can be expanded with adapters to meet different installation needs.
  2. Common Advantages: All models are equipped with IO-Link, featuring strong anti-vibration, anti-interference and long-term stability. They are suitable for air, compressed gas, water, oil and non-corrosive media.
  3. Selection Tips: Choose PI/PM series (IP69K) for hygienic applications, PT/PU for mini equipment, PN/PE for general industry, PL for heavy-duty hydraulics, and PY for homogenization equipment.
Frequently Asked Questions
Q1: What's the measuring range of this sensor?
A1: It covers both pressure and vacuum, typical ranges from -1…0 bar up to 0…600 bar for different models.
Q2: Does it really work stably in vibrating machines?
A2: Yes. Anti-vibration and anti-shock design, no drift or false triggers under hydraulic/pneumatic vibration.
Q3: Is IP67 enough for wet and dusty workshops?
A3: Yes, IP67 is fully dustproof and waterproof, works reliably in humid, oily, and dirty industrial sites.
Q4: Does this sensor support IO-Link?
A4: Yes, IO-Link 1.1 is supported for remote setup, parameter copy, and real-time status diagnosis.
Q5: What output signals are available?
A5: Common types: PNP/NPN switching output, 4-20mA & 0-10V analog output, compatible with most PLCs.
Q6: Can it be used for both gas and liquid media?
A6: Yes, suitable for air, compressed gas, water, oil, and most non-corrosive media.
Q7: How accurate is it?
A7: High precision, mostly ±0.3% or ±0.5% FS, stable readings with no long-term drift.
Q8: Is the installation complicated?
A8: No, compact size, standard M12 connector & G1/4 process connection, plug-and-play, very easy.
Q9: Will it fail often in harsh environments?
A9: Very durable. Stainless steel diaphragm, strong anti-interference, low failure rate, long service life.
Q10: Can I use it for food, pharma or hygienic fields?
A10: Yes, hygienic/flush diaphragm versions are available, IP69K, easy to clean, fit CIP/SIP processes.
Q11: Does it have a status indicator?
A11: Yes, built-in LED display shows working status, switching point, and error code clearly.
Q12: What's the working voltage?
A12: Standard 10…30V DC, wide voltage design, stable even with slight power fluctuation.
