Original Autonics Incremental Rotary Encoder E40S E50S EP58S Sensor
Original Autonics Incremental Rotary Encoder E40S E50S EP58S Sensor
Original Autonics Incremental Rotary Encoder E40S E50S EP58S Sensor
Original Autonics Incremental Rotary Encoder E40S E50S EP58S Sensor
Specifications
Encoder Type :
Incremental Rotary
Certification :
CE、RoHS 、ISO 9001
Output Phase :
A, B, Z Phase (Standard)
Freight Charge :
For Industrial Equipment (E.G., PLC Modules, Inverters..), Shipping Cost Varies By Package Weight/Volume And Delivery Location. Contact Our Sales Team For A Customized Shipping Solution And Quote
Price :
$35 - $125
Startup Torque :
Max. 40gf·cm to 70gf·cm
Delivery Time :
3-5Workdays
Shipping Term :
International Express（DHL/FEDEX/TNT/UPS/ARAMEX）/Sea Freight / Air Freight / International Special Line
Packaging Details :
Original
Resolution (PPR) :
100 / 360 / 500 / 1000 / 2500 / 5000 PPR
Place of Origin :
South Korea
Shaft Type :
Solid Shaft (6mm / 8mm / 10mm)
MOQ :
1
Connection Type :
Axial / Radial Cable Out
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Brand Origin :
South Korea (100% Authentic)
Brand Name :
Autonics
Description
Original Autonics Incremental Rotary Encoder E40S E50S EP58S Sensor
Boost your automation efficiency with Autonics Incremental Rotary Encoders - the global benchmark for high-performance, cost-effective motion control. Engineered in South Korea, the E40S (40mm), E50S (50mm), and EP58S (58mm) series provide precise feedback for speed, position, and angle measurement. Known as the "King of Cost-Performance," Autonics is the ideal alternative to expensive European or Japanese brands, offering rugged reliability and easy integration for industrial machinery in Southeast Asia, Latin America, and beyond.
Product Highlights
  • Ultimate Cost-Performance: Superior South Korean engineering at a fraction of the cost of premium competitors.
  • Diverse Resolution Options: Offers a wide range of pulses per revolution (PPR) from 1 to 5000 for tailored precision.
  • Versatile Output Signals: Supports Totem Pole, NPN Open Collector, PNP Open Collector, and Line Driver outputs.
  • Robust & Compact Design: Available in 40mm, 50mm, and 58mm diameters to fit diverse installation spaces.
  • Superior Noise Immunity: Advanced circuitry design minimizes electromagnetic interference for stable data transmission.
  • Rugged Industrial Build: Features IP50 protection rating (standard) with optional IP64 waterproof models for harsh environments.
Models & Parameter Selection
Series Outer Diameter Shaft Diameter Max. Resolution Power Supply Output Type
E40S Series 40 mm 6 mm 5000 PPR 5VDC / 12-24VDC Totem Pole, NPN, PNP, Line Driver
E50S Series 50 mm 8 mm 5000 PPR 5VDC / 12-24VDC Totem Pole, NPN, Line Driver
EP58S Series 58 mm 10 mm 5000 PPR 5VDC / 12-24VDC Totem Pole, NPN, Line Driver
Application Fields
  • Packaging Machinery: Controlling conveyor speed and bag-cutting positions.
  • Textile Industry: Monitoring spindle speed and fabric tension.
  • Elevator & Lift Systems: Providing precise floor leveling and door control.
  • CNC Machine Tools: Feedback for spindle orientation and tool changers.
  • Printing Presses: Ensuring accurate color registration and paper feeding.
Frequently Asked Questions
Q: Can Autonics encoders replace Omron or Nemicon brands?
A: Yes, as long as the mechanical dimensions (diameter/shaft) and electrical specs (output/voltage) match, Autonics is a perfect, budget-friendly replacement.
Q: What is the difference between Totem Pole and Line Driver output?
A: Totem Pole is standard for short distances; Line Driver is recommended for long-distance transmission to reduce signal noise and loss.
Q: Do you offer the 5VDC version for Line Driver models?
A: Yes, we provide the 5VDC Line Driver version which is standard for high-speed controller interfaces.
Q: Is the 2-meter cable included?
A: Yes, all standard E40S/E50S models come with a high-quality 2-meter axial or radial cable.
Q: What does the "S" stand for in the model name?
A: The "S" indicates a Shaft type (solid shaft). We also offer "H" for Hollow shaft types upon request.
Q: How do I verify if the product is a genuine Autonics item?
A: All our products are 100% original with factory seals, serial numbers, and original South Korean packaging.
Q: What is the warranty period?
A: We provide a 12-month standard international warranty for all Autonics sensors.
