36494 Pneumatic Air Rubber Bellows Compatible Air Spring for Festo EB-165-125
36494 Pneumatic Air Rubber Bellows Compatible Air Spring for Festo EB-165-125
36494 Pneumatic Air Rubber Bellows Compatible Air Spring for Festo EB-165-125
36494 Pneumatic Air Rubber Bellows Compatible Air Spring for Festo EB-165-125
36494 Pneumatic Air Rubber Bellows Compatible Air Spring for Festo EB-165-125
36494 Pneumatic Air Rubber Bellows Compatible Air Spring for Festo EB-165-125
36494 Pneumatic Air Rubber Bellows Compatible Air Spring for Festo EB-165-125
36494 Pneumatic Air Rubber Bellows Compatible Air Spring for Festo EB-165-125
Specifications
Brand Name :
AIRSUSTECH
Model Number :
2B7070
Certification :
ISO/TS16949:2009
Place of Origin :
Guangzhou,China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T, Western Union, Paypal or Others
Supply Ability :
1000PCS/Week
Delivery Time :
5-8 Working Days
Packaging Details :
Strong Carton Box or as Customers Requirement
Brand :
AIRSUSTECH
Product Number :
2B7070
Static Height :
162 MM
Port Size :
G1/4
Festo :
EB-165-125
Structure :
Double Convoluted
Purpose :
Reduce Shock
Compatibility :
Easy to Replace
Description

Wholesale Festo 36494 Pneumatic Air Rubber Bellows Compatible Air Spring Supplier

2B7070 Detailed Data

Dimensions - Design Height: 162 mm

Dimensions - Natural Diameter: 146 mm

Dimensions - Center to Center Diameter: 44.5 mm

Air Hole Standard: G 1/4

Screw Type: 2×M8×1.25

2B7070 Technical Data Sheet

Pressure P [bar] 3 4 5 6 7 8 Vol. V[l]
Force (Load) [kN] 1.9 2.5 3.2 3.8 4.5 5.2 1.7
Spring Rate [N/cm] 460 595 730 860 995 1125
Natural Frequency [Hz] 2.5 2.5 2.4 2.4 2.4 2.4

Pressure p [bar] 2 4 5 6 7 8 Vol.[l]
Height H [mm] 180 1.6 2.3 2.9 3.5 4.1 4.7 1.8
160 2.4 3.2 3.9 4.7 5.6 6.4 1.6
140 2.9 3.9 4.8 5.8 6.8 7.8 1.5
120 3.4 4.5 5.7 6.8 7.9 9.2 1.3
100 3.9 5.2 6.5 7.8 9.1 10.4 1.1
80 4.3 5.7 7.1 8.5 10.0 11.4 0.7


OEM Manufacturer

Festo OEM Manufacturer 36494
Festo OEM Manufacturer EB-165-125

Festo OEM Manufacturer EB165125

Festo OEM Manufacturer EB 165 125

Application of Industrial Air Springs in the Papermaking Industry‌

1. Reduce vibration and shock:

Industrial air springs are used in papermaking equipment such as paper dryers, calenders, pulpers, and presses to reduce the severe vibration and shock caused by high-speed operation. This dampening effect helps extend equipment life and reduce downtime, thereby increasing production efficiency.

2. Support and stability:

By adjusting the internal air pressure, air springs provide stable support for papermaking equipment to adapt to varying loads. This support ensures smooth equipment operation at high speeds and contributes to improving paper quality and operational efficiency.

3. Bearings and conveyor belt supports:

In the bearing support of papermaking equipment, the air spring system can effectively reduce frictional resistance and bearing wear, thus improving the accuracy and reliability of the equipment. They also support conveyor belts, reducing frictional resistance and wear and extending their service life.

We Have Other Convoluted Air Spring Replacements to Festo Air Bellows

EB-80-20 EB-145-60
EB-215-155 EB-385-230
EB-165-125 EB-325-215
EB-80-45 EB-250-85
EB-325-95 EB-385-115
EB-145-100
