Specifications
Brand Name :
AIRSUSTECH
Model Number :
1B130070
Certification :
ISO/TS16949:2009
Place of Origin :
Guangzhou, China
MOQ :
6 pieces
Price :
USD49.9/PC-USD59.9/PC
Payment Terms :
T/T, Western Union, Paypal or Others
Supply Ability :
1000PCS/Week
Delivery Time :
5-8Working Days
Packaging Details :
Strong Carton Box or as Customers Requirement
Material :
Rubber+Steel
Pressure Ability :
0.2-0.8 MPa
Function :
Reduce Shock
Convolutions :
Single
Warranty :
12 months
Categories :
Industrial Air Springs
Packing :
Carton/Cartpns
Description

1B130070 Rubber Single Vibration Industrial Air Spring Reduce Shock

Product Description:

  • 100% Brand New.
  • Durable and long service life.
  • Direct replacement for your old or broken one, easy installation.
  • Built to meet standard specification, strictly follow factory quality control.
  • Due to the light and screen difference, the item's color may be slightly different from the pictures.

Technical Data of 1B130070 Industrial Air Spring:

Air Inlet/Gas Hole G 1/4
Rubber Bellow Rubber Bellow MAX Diameter 145mm
Maximum Height 83mm
Minimum Height 53mm
The Stroke 30mm
Effect Diameter 100mm
Blind Nut/Screw Top Cover Plate Screw (Nut) Tooth M10X15mm
Bottom Cover Plate Screw(Nut) Tooth M10X15mm
Screw Center Distance Of Top Cover Plate 44.5mm
Screw Center Distance Of Bottom Cover Plate 44.5mm
Cover Plate The Top Cover Plate Diameter 114mm
The Bottom Cover Plate Diameter 114mm

1B130070 Air Spring Technical Parameters Table:

Load Capacity Inflation Pressure 0.2 MPa 0.3 MPa 0.4 MPa 0.5 MPa 0.6 MPa 0.7 MPa 0.8 MPa
53 mm 230 341 448 559 681 793 915
66 mm 180 277 366 468 560 656 750
70 mm 159 251 337 422 511 601 750
79 mm 146 225 297 369 438 519 587
83 mm 120 177 253 294 357 417 489
92 mm 69 103 138 174 214 253 296

Function of 1B130070 Industrial Air Spring:

The main function of the 1B130070 Air Spring is to suppress and absorb the shock and vibration generated during driving. It helps to provide a smoother and more comfortable driving experience for the truck's occupants by reducing the impact of bumps and uneven surfaces. In addition, it helps reduce wear on tires and suspension components, improves fuel economy by reducing engine vibration, and reduces noise levels in the cockpit.

1B130070 Rubber Single Vibration Industrial Air Spring Reduce Shock

1B130070 Rubber Single Vibration Industrial Air Spring Reduce Shock
