Specifications
Brand Name :
AIRSUSTECH
Model Number :
1B8X4
Certification :
ISO/TS16949, ISO9001
Place of Origin :
Guangzhou, China
MOQ :
3 pieces
Payment Terms :
T/T, Western Union,Paypal or Others
Supply Ability :
1000pcs/week
Delivery Time :
3-8 Working Days
Packaging Details :
Strong Carton Box or as Customers Requirement
Model NO. :
1B8X4
Warranty :
One Year
Pressure Ability :
0.2-0.8 M PA
Plates :
Crimped Type
Trademark :
Neutral
Transport Package :
Cartons or as customer's need
Specification :
24*24*22 cm
Origin :
China
HS Code :
8708809000
Port :
Huangpu, China
Material :
Rubber and Iron
Position :
Rear
OEM :
93113
Type :
Suspension Spring
N.W. :
2.4 Kg
Description

Air Spring STANDARD Code 93113 Connection P1 Airsustech 1B8X4 Bellow No. 110

AIRSUSTECH1B8X4 Cross other OEM:

AIRSUSTECH: 1B8X4 AIRSUSTECH: Style 8X4
Air Spring STANDARD Code 93113 Style 110
Connection P1 TORPRESS MODEL 110
Goodyear Part Number:1B8-55 Firestone Style 11
Goodyear Part Number:1B8 55 Contitech:FS120-1
Goodyear Part Number:1B8 55 Contitech:FS120 1
Contitech Part Number:FS 120-10 C Contitech:FS1201
Contitech Part Number:FS120-10 C Firestone Part Number:W01-358-756
Contitech Part Number:FS 120 10 C Firestone Part Number:W01 358 756
Continental Part Number:FS 120-10 C Firestone Part Number:W01358756
Continental Part Number:FS120-10 C Firestone Rubber bellows only:W01-358-013
Continental Part Number:FS 120 10 C Firestone Rubber bellows only:W01 358 013
Enidine Part Number:YI1-B8-550 Firestone Rubber bellows only:W01358013
Enidine Part Number:YI1B8550 Enidine Part Number:YI1 B8-550

Product Description of 1B8X4 Refer To Air Spring STANDARD Code 93113

Top Cover Plate Diameter: 114.5 mm

Bottom Piston Number: 44.5 mm

Bottom Cover Plate Diameter: 114.5 mm

Screw Center Distance : 44.5 mm

Distance Gas Hole Between Nut: 35 mm

Air inlet:1/4” NPT F

Top Cover Plate Screw (Nut) Tooth : 2pcsX3/8-16UNC

Bottom Cover Plate Screw (Nut) Tooth : 2pcsX3/8-16UNC

Rubber Bellows MAX Diameter(Maximum Diameter): 230 mm

Rubber Bellows Natural Diameter 210 mm

The Working Stroke : MAX 151 mm to MIN 51 mm

Compressed Height: 100 mm

Technical Data

  • Min. pressure - 0 psi
  • Return force to min. height - <45LBF/200N
  • Overall Weight - 2.4KG
  • Min. Design Height - 50MM
  • Inst.Space Required - 240MM
  • Max. Stroke - 90MM

Technical performance parameter list of AIRSUSTECH 1B8X4 air spring:
Bearing
load
Power
(kg)		 Inflation pressure 0.2MPa 0.3MPa 0.4MPa 0.5MPa 0.6MPa 0.7MPa 0.8MPa 0.7MPa
Volume(dm³)
Installation height
55(mm) 433 664 897 1131 1354 1585 1822 1.11
78(mm) 396 598 803 1015 1236 1441 1647 1.34
101(mm) 314 471 646 820 996 1175 1321 1.47
124(mm) 208 318 434 555 675 798 920 1.79
130(mm) 167 258 348 438 535 636 733 1.86
147(mm) 56 96 133 179 226 274 331 2.04
149(mm) 19 41 64 93 126 164 208 2.08
155(mm) 2 10 20 41 51 80 100 2.15
Stiffness and frequency at design height Vertical stiffness(Kg/cm) 132 170 182 203 230 268 285
Stiffness and frequency at design height Natural frequency Hz 4.45 4.06 3.62 3.4 3.28 3.25 3.12
Stiffness and frequency at design height Natural frequency cpm 267 244 217 204 197 195 187

PURCHASE ORDER DATA

Type Air Inlet Order No.
with crimped plates

1/4 NPT

0 in. excentrical
