Double Convoluted Air Spring Assy Firestone W01-358-6960 Contitech FD 200-25 507 In Planter Or Seeder
Double Convoluted Air Spring Assy Firestone W01-358-6960 Contitech FD 200-25 507 In Planter Or Seeder
Double Convoluted Air Spring Assy Firestone W01-358-6960 Contitech FD 200-25 507 In Planter Or Seeder
Double Convoluted Air Spring Assy Firestone W01-358-6960 Contitech FD 200-25 507 In Planter Or Seeder
Double Convoluted Air Spring Assy Firestone W01-358-6960 Contitech FD 200-25 507 In Planter Or Seeder
Double Convoluted Air Spring Assy Firestone W01-358-6960 Contitech FD 200-25 507 In Planter Or Seeder
Specifications
Brand Name :
AIRSUSTECH
Model Number :
2B6960
Certification :
ISO/TS16949:2009
Place of Origin :
Guangzhou, China
MOQ :
3Pieces
Payment Terms :
T/T, Western Union, Paypal or Others
Supply Ability :
1000PCS/Week
Delivery Time :
5-8 Working Days
Packaging Details :
Strong Carton Box or as Customers Requirement
Material :
Rubber and mental
Certifications :
ISO/TS16949:2009
Warranty :
12 months
Packing :
Neutral Box Or As Customers' Request
Condition :
100% Brand-New
Applications :
Planter/Seeder Or Others
Sample :
Available
Cross Reference :
Firestone W01-358-6960 Contitech FD 200-25 507
HS Code :
8708809000
Description

Double Convoluted Firestone W01-358-6960 Contitech FD 200-25 507 Air Spring Assy Used In Planter Or Seeder

Cross reference

Air spring supplier: Firestone

Supplier number: W01-358-6960; W013586960; W01 358 6960; WO1-358-6960; WO13586960; WO1 358 6960

Air spring supplier: Contitech

Supplier number: FD 200-25 507; FD 200 25 507; FD 200-25507; FD200-25 507; FD200-25507; FD20025507

Cross reference: 161339


Air spring supplier: Triangle

Supplier number: 6332/4507

Air spring supplier: Granning
Supplier number: 7025

Air spring supplier: Tuthill
Supplier number: 7025

Part Number: ABSP2B12RA-6960
Condition: New
Double Convoluted Air Bag
Firestone Bellows Number: 20F-2
Firestone Part Number: W01-358-6960

Specifications and Tecnical Parameters: 2B6960

1. Max. OD

262mm

2. Air hole/air inlet/air fitting air hole/air inlet

offset, 44.5mm

3. Cover plate diameter(width)

160 mm

4. The serew center distance

89mm

5. Min. Height

95mm

6. Max. height

325mm

7. Bumper block/bumper

Yes

8. Belt loop/Girdle ring/Girdle hoop

one piece

The type of air spring can be used in planter or seeder

This air spring assy can be used in agricultural industry, such as planter or seeder. It is more and more common to use air spring. It has following feature.

Row unit downforce
Long cycle life
Dirt resistant

The picture

Double Convoluted Air Spring Assy Firestone W01-358-6960 Contitech FD 200-25 507 In Planter Or Seeder
