Specifications
Brand Name :
Canroon
Model Number :
CR2100-010B-14TW1
Certification :
CE
Place of Origin :
China
MOQ :
1 pcs
Price :
negotiable
Payment Terms :
T/T
Supply Ability :
500 sets/ month
Delivery Time :
5-10 working days
Packaging Details :
carton or wooden box
Input voltage :
400V
Input Frequency :
50-60Hz
Input Ampere :
15A
Output Power :
10KW
Output Frequency :
10-40KHz
Cooling water pressure :
4-6 bar, ≥12L/min
Description

Induction Welding Heating Brazing Equipment For Curing / Forging / Straightening

Induction brazing heating equipment

Product features:

1. High efficient: thermoelectric conversion efficieny: >85%;

2. Enviromental friendly: zero pollution, zero discharge;

3. Intelligent: PID temperature closed-loop control, precise temperature control;

4. Wide application: for all metal wiredrawing products, including metal or alloy such as copper, iron, zinc, tin, aluminum, silver, stainless steel, titanium, nickel.

5. Operation interface: humanized MMI, chinese/ English available;

6. Multiple control interfaces: Heating process can be controlled accurately by feedback signal sent to the microcontroller from remote control unit; support 0-10v, 4-20mA analog signal control; support RS-485 communication;

7. Automation integration: Quickly and easily integrated into automated production lines;

8. Multiple heating modes: constant power mode, Time VS Power heating mode; Multi-segment heating mode;

Model

 Rated input voltage and frequency Rated input power Rated input current Output frequency Cooling water pressure/ flow rate Dimension(mm)
CR2100-010B-14TW1 3 Phase/ 400V(±20%) 50/60Hz 10KW 15A 10-40KHZ 4-6 bar, ≧12L/min 581.5*283*334
CR2100-015B-14TW1 3 Phase/ 400V(±20%) 50/60Hz 15KW 22A 10-40KHZ 4-6 bar, ≧12L/min 581.5*283*334
CR2100-020B-14TW1 3 Phase/ 400V(±20%) 50/60Hz 20KW 30A 10-40KHZ 4-6 bar, ≧12L/min 581.5*283*334
CR2100-025B-14TW1 3 Phase/ 400V(±20%) 50/60Hz 25KW 37A 10-40KHZ 4-6 bar, ≧12L/min 581.5*283*334
CR2100-030B-14TW1 3 Phase/ 400V(±20%) 50/60Hz 30KW 45A 10-40KHZ 4-6 bar, ≧19L/min 581.5*283*334
CR2100-035B-14TW1 3 Phase/ 400V(±20%) 50/60Hz 35KW 53A 10-40KHZ 4-6 bar, ≧19L/min 581.5*283*334
CR2100-040B-14TW1 3 Phase/ 400V(±20%) 50/60Hz 40KW 60A 10-40KHZ 4-6 bar, ≧19L/min 581.5*283*334
CR2100-050B-14TW1 3 Phase/ 400V(±20%) 50/60Hz 50KW 75A 10-40KHZ 4-6 bar, ≧19L/min 581.5*283*334
