30KW Induction Brazing Machine for Industrial Heating Applications
30KW Induction Brazing Machine for Industrial Heating Applications
30KW Induction Brazing Machine for Industrial Heating Applications
30KW Induction Brazing Machine for Industrial Heating Applications
30KW Induction Brazing Machine for Industrial Heating Applications
30KW Induction Brazing Machine for Industrial Heating Applications
30KW Induction Brazing Machine for Industrial Heating Applications
30KW Induction Brazing Machine for Industrial Heating Applications
30KW Induction Brazing Machine for Industrial Heating Applications
30KW Induction Brazing Machine for Industrial Heating Applications
30KW Induction Brazing Machine for Industrial Heating Applications
30KW Induction Brazing Machine for Industrial Heating Applications
Specifications
Brand Name :
ZHENGZHOU LANSHUO
Model Number :
LSW-30
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 SET
Price :
1200-2000USD
Payment Terms :
T/T
Delivery Time :
3-5 WORKING DAYS
Packaging Details :
PLYWOOD PACKAGING
Power :
30kw
DC current :
50A
DC voltage :
500V
Input voltage :
Three-phase 380V/420V/440V,50-60HZ
Heating frequency :
25-50KHZ
Air switch :
3*100A
Ground wire :
1mm²
Water pressure :
0.15-0.2MPa
Input power cord :
10mm²copper wire
Input power control switch :
3*100A
Equipment grounding wire :
1mm²soft copper wire
Description

parameter

Power

30KW

DC current

50A

DC voltage

500V

Input voltage

Three-phase

380V/420V/440V,50-60HZ

Heating frequency

25-50KHZ

Air switch

3*100A

Ground wire

1mm²

Water pressure

0.15-0.2MPa

Dimension(after packing)

750mm*350mm*720mm

Weight(after packing)

58KG


Power

installation

Input power cord

10mm²copper wire

Input power control switch

3*100A

Equipment grounding wire

1mm²soft copper wire


Cooling water installation

Number of water in the control cabinet

water intake:one

water outlet:one

Water pipe specification

Inlet water pipe’s inner diameter :25mm

Water outlet pipe’s inner diameter :25mm

Cooling system

(two choices)

Use 2m³water tank + 1.5kw circulating pump(head 25m, flow 10m³/h)

2P chiller


List of goods

30kw induction brazing machine

1 set

Foot switch

1 set

Induction coil(according to the workpiece design)

1 set


Pictures:

30KW Induction Brazing Machine for Industrial Heating Applications

30KW Induction Brazing Machine for Industrial Heating Applications

30KW Induction Brazing Machine for Industrial Heating Applications

30KW Induction Brazing Machine for Industrial Heating Applications


CE:

30KW Induction Brazing Machine for Industrial Heating Applications
