1400KW Induction Melting Furnace for Iron Steel Copper 2000kg Capacity
1400KW Induction Melting Furnace for Iron Steel Copper 2000kg Capacity
1400KW Induction Melting Furnace for Iron Steel Copper 2000kg Capacity
1400KW Induction Melting Furnace for Iron Steel Copper 2000kg Capacity
1400KW Induction Melting Furnace for Iron Steel Copper 2000kg Capacity
1400KW Induction Melting Furnace for Iron Steel Copper 2000kg Capacity
1400KW Induction Melting Furnace for Iron Steel Copper 2000kg Capacity
1400KW Induction Melting Furnace for Iron Steel Copper 2000kg Capacity
1400KW Induction Melting Furnace for Iron Steel Copper 2000kg Capacity
1400KW Induction Melting Furnace for Iron Steel Copper 2000kg Capacity
Specifications
Brand Name :
Lanshuo
Model Number :
KGPS-2T/1400KW
Certification :
CE ISO EAC
Place of Origin :
China
MOQ :
1 set
Price :
USD 25000-30000 per set
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
300 sets per year
Delivery Time :
7-10 working days
Packaging Details :
plywood case, about 13cbm, about 4T
Type :
Induction Melting Furnace
Power Source :
electricity
Melting Material :
500kg 750kg 1000kg 2000kg Iron Steel Copper Aluminum Lead Gold Silver
Rated Temperature :
1800°c
Rated Power :
1400KW
Voltage :
3-phase 660v, 50/60HZ
MF Frequency :
800HZ
Medium Voltage :
1480v Phase
DC Voltage :
990V Phase
DC Current :
1570A Phase
Description

1000kg 2000kg iron steel copper bronze aluminum scrap melting furnace industrial furnace

1. Brief Introduction of Medium Frequency Induction Melting Furnace:

Through long-term practical test, constant power (energy-saving) Intermediate frequency induction melting furnace has been widely praised among customers. What’s more, our melting furnace has made some improvements based on its original type, and its property is becoming more excellent.

1400KW Induction Melting Furnace for Iron Steel Copper 2000kg Capacity

2. Features of KGPS induction melting furnace:

a. High melting rate.

b. Good-quality molten steel, high casting product yield.
c. High power factor. During the machine’s operation, the power factor can reach over 97%.

d. No harm to the power gird.

e. Low power consumption, saving over 10% energy.

f. High start-up success rate. Under any load, the start-up success rate is 100%.

g. The main control panel adopts plug-in connector, easier maintenance.
h. Simple to install. Installation can be done by unprofessional workers very easily.
i. The melting furnace adopts series thyristor, making the SCR damage rate to a minimum.


3. Technical Parameter of KGPS-1400 Induction Melting Furnace:

Model KGPS-2T/1400KW
Rated Power 1400kw
Rated Capacity 2ton iron / steel
Voltage 660V, 50/60HZ
MF Frequency 800HZ
Medium Voltage 1480V Phase
DC Voltage 990V Phase
DC Current 1570A Phase
Rated Temperature 1800°C
Closed Loop Water Cooling Tower LSN-130B

1400KW Induction Melting Furnace for Iron Steel Copper 2000kg Capacity

4. Large Induction Melting Furnace Application:

(1) iron, pig iron, cast iron;

(2) steel, stainless steel, cast steel, carbon steel and bearing steel;

(3) gold, silver, platinum;

(4) copper, brass, bronze;

(5) aluminum, aluminum alloy;

(6) zinc, lead, tin, magnesium, nickel, titanium.

1400KW Induction Melting Furnace for Iron Steel Copper 2000kg Capacity

5. Certificates

1400KW Induction Melting Furnace for Iron Steel Copper 2000kg Capacity

1400KW Induction Melting Furnace for Iron Steel Copper 2000kg Capacity

1400KW Induction Melting Furnace for Iron Steel Copper 2000kg Capacity
