1400KW Induction Melting Furnace for Iron Steel Copper 2000kg Capacity
1400KW Induction Melting Furnace for Iron Steel Copper 2000kg Capacity
1400KW Induction Melting Furnace for Iron Steel Copper 2000kg Capacity
1400KW Induction Melting Furnace for Iron Steel Copper 2000kg Capacity
1400KW Induction Melting Furnace for Iron Steel Copper 2000kg Capacity
1400KW Induction Melting Furnace for Iron Steel Copper 2000kg Capacity
1400KW Induction Melting Furnace for Iron Steel Copper 2000kg Capacity
1400KW Induction Melting Furnace for Iron Steel Copper 2000kg Capacity
1400KW Induction Melting Furnace for Iron Steel Copper 2000kg Capacity
1400KW Induction Melting Furnace for Iron Steel Copper 2000kg Capacity
Specifications
Brand Name :
Lanshuo
Model Number :
KGPS-1400
Certification :
CE ISO EAC
Place of Origin :
China
MOQ :
1 set
Price :
USD 25000-30000 per set
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
300 sets per year
Delivery Time :
7-10 working days
Packaging Details :
plywood case, about 13cbm, about 4T
Power Source :
electricity
Type :
Induction Melting Furnace
Rated Power :
1400KW
DC Voltage :
990V Phase
MF Frequency :
800HZ
Medium Voltage :
1480v Phase
Voltage :
3-phase 660v, 50/60HZ
Melting Material :
500kg 750kg 1000kg 2000kg Iron Steel Copper Aluminum Lead Gold Silver
Rated Temperature :
1800°c
DC Current :
1570A Phase
Description
2000kg 2Ton Iron Steel Melting Furnace Electric Smelting Machine Metal Melting Industrial Furnace
1000kg 2000kg Iron Steel Copper Bronze Aluminum Scrap Melting Furnace
Medium Frequency Induction Melting Furnace Overview

Our constant power (energy-saving) intermediate frequency induction melting furnace has been extensively tested and widely praised by customers. We've made significant improvements to the original design, resulting in superior performance characteristics.

1400KW Induction Melting Furnace for Iron Steel Copper 2000kg Capacity

Key Features of KGPS Induction Melting Furnace
  • High melting rate for efficient production
  • Produces good-quality molten steel with high casting product yield
  • High power factor exceeding 97% during operation
  • No harmful effects on power grid
  • Low power consumption with over 10% energy savings
  • 100% start-up success rate under any load condition
  • Main control panel with plug-in connectors for easier maintenance
  • Simple installation process requiring minimal technical expertise
  • Series thyristor design minimizes SCR damage rate
Technical Parameters of KGPS-1400 Induction Melting Furnace
Model KGPS-2T/1400KW
Rated Power 1400KW
Rated Capacity 2ton iron/steel
Voltage 660V, 50/60HZ
MF Frequency 800HZ
Medium Voltage 1480V Phase
DC Voltage 990V Phase
DC Current 1570A Phase
Rated Temperature 1800°C
Closed Loop Water Cooling Tower LSN-130B
1400KW Induction Melting Furnace for Iron Steel Copper 2000kg Capacity
Industrial Applications

Our large induction melting furnace is suitable for processing various metals including:

  • Iron, pig iron, cast iron
  • Steel, stainless steel, cast steel, carbon steel and bearing steel
  • Gold, silver, platinum
  • Copper, brass, bronze
  • Aluminum, aluminum alloy
  • Zinc, lead, tin, magnesium, nickel, titanium
1400KW Induction Melting Furnace for Iron Steel Copper 2000kg Capacity
Certifications
1400KW Induction Melting Furnace for Iron Steel Copper 2000kg Capacity 1400KW Induction Melting Furnace for Iron Steel Copper 2000kg Capacity1400KW Induction Melting Furnace for Iron Steel Copper 2000kg Capacity
