Specifications
Model Number :
HF-25KW
Operation :
Automatic and Manual
Mixing Heat Exchanger Type :
Water Cool
Price :
0.1
Delivery Time :
3days
Frequency :
30-80kHz
The Range of Operating Voltage :
340-430V AC
HS Code :
8514400090
Supply Ability :
1000 sets/ month
Product Name :
High Frequency Induction Heating Equipment
Packaging Details :
ply wooden box package
Power :
25kw
Work Power :
3*380V/415V/440V/480V 50-60Hz
Transport Package :
Wooden Box
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Model NO. :
HF-25KW
Input Current :
25A
Core :
IGBT
Size :
Main Parts:640*280*550mm
Trademark :
ORD
Ceramic Heating Equipment Type :
Induction Heating Machine
Production Capacity :
10, 000sets
Place of Origin :
CHINA
Structure Material :
Metal Material
MOQ :
1
Type :
Induction Heating
Origin :
China
Certification :
CE ROHS SGS
Specification :
CE, SGS, ISO
Brand Name :
OURUIDA
Weight :
Mainparts:42kg
Recuperative Heat Exchanger Type :
IGBT
Heat Transfer Surface :
Induction Heating Machine
Description

induction heating generator for welding, smelting ,forging of the metals (HF-25KW):

Induction Heating Generator for Welding, Smelting, Forging of The Metals (HF-25KW)

Induction Heating Generator for Welding, Smelting, Forging of The Metals (HF-25KW) Induction Heating Generator for Welding, Smelting, Forging of The Metals (HF-25KW) Induction Heating Generator for Welding, Smelting, Forging of The Metals (HF-25KW)

Advantage:

  • More than ten years experience,stable and goods performance
  • CE certificated
  • Copperated with CHOW TAI FOOKS, Matsushita, Foxconn, Media, Gree a6nd ZHIGAO Air conditioner.
  • Suitable for a large range, heating, quenching, forging, melting, solding and so on.

Main characteristics:

  1. IGBT module and Inverting technologies of third generation been used; Higher reliability and lower maintenance cost.
  2. 100% Duty cycle, continuous working is allowed at maximum power output.
  3. Display of heating power and heating current and oscillating frequency;
  4. Simple to install, Installation can be done by unprofessional person very easily;
  5. Light weight
  6. Advantages of the model with timer: The power and the operating time of the heating period and the retain period can be preset respectively, to realize a simple heating curve, this model is suggested to use for batch production to improve the repeatability;

Induction Heating Generator for Welding, Smelting, Forging of The Metals (HF-25KW)

Packing Photos:

Induction Heating Generator for Welding, Smelting, Forging of The Metals (HF-25KW)

 Type HF-25AB/25A
 Work Power  3*380v/415v/440v/480v 50-60hz
 The range of operating voltage  340-430V AC
 Output power  25KW
 Input current  25A
 Fluctuating frequency  30-80khz
 Timing (Heat time,Retain time,Cool time)  1-99S
 The flow rate of cooling water  0.15 Mpa 9L/Min
 Water temperature protection point  40centidegree
 Duty cycle  100% (40degree room temperature)
 Weight  Mainparts:42Kg
 Size Main Parts:640*280*550mm
