IGBT portable Hf Induction Heating Equipment Hf-40kw
IGBT portable Hf Induction Heating Equipment Hf-40kw
IGBT portable Hf Induction Heating Equipment Hf-40kw
IGBT portable Hf Induction Heating Equipment Hf-40kw
IGBT portable Hf Induction Heating Equipment Hf-40kw
IGBT portable Hf Induction Heating Equipment Hf-40kw
IGBT portable Hf Induction Heating Equipment Hf-40kw
IGBT portable Hf Induction Heating Equipment Hf-40kw
IGBT portable Hf Induction Heating Equipment Hf-40kw
IGBT portable Hf Induction Heating Equipment Hf-40kw
Specifications
Frequency :
30-80kHz
The Range of Operating Voltage :
340-430V AC
Trademark :
ORD
Brand :
Ord
Certification :
CE/ ROHS /SGS
Structure :
Vertical Type
Origin :
China
Model Number :
HF-40KW
Length of Cable :
5m+2m Flexible Connection
Core :
IGBT
Specification :
CE, SGS, ISO
Price :
1800
Working Application :
Heating, Forging, Quenching, Melting, Annealing
Style :
Induction Heating Machine
Work Power :
3*380V/415V/440V/480V 50-60Hz
Principle :
Induction Heating
Model NO. :
HF-40KW
HS Code :
8514400090
Brand Name :
OURUIDA
Transport Package :
Wooden Box
Production Capacity :
10, 000sets
Power :
40kw
Place of Origin :
CHINA
MOQ :
1
Input Current :
40A
Description
IGBT Protable High Frequency Induction Heating equipment HF-40KW with 2m  flexible connexion and 5m cable
IGBT portable Hf Induction Heating Equipment Hf-40kw
Advantage:
  1. More than26 years experience,stable and goods performance
  2. CE certificated
  3. Copperated with CHOW TAI FOOKS, Matsushita,Foxconn, Media, Gree and ZHIGAO Air conditioner.
  4. Suitable for a large range, heating, quenching, forging, melting, solding and so on.
  5. 2 Transformer ratios more options connect induction coil
  6. Coaxial Connection Flexible, can handle the flexible to work the workpiece that normal coil can not get it.
Main characteristics:
  1. IGBT module and Inverting technologies of third generation been used; Higher reliability and lower maintenance cost.
  2. 100% Duty cycle, continuous working is allowed at maximum power output.
  3. Display of heating power and heating current and oscillating frequency;
  4. Simple to install, Installation can be done by unprofessional person very easily;
  5. Light weight
  6. Advantages of the model with timer: The power and the operating time of the heating period and the retain period can be preset respectively, to realize a simple heating curve, this model is suggested to use for batch production to improve the repeatability;
IGBT portable Hf Induction Heating Equipment Hf-40kw IGBT portable Hf Induction Heating Equipment Hf-40kw
Packing Photos:
IGBT portable Hf Induction Heating Equipment Hf-40kw IGBT portable Hf Induction Heating Equipment Hf-40kw IGBT portable Hf Induction Heating Equipment Hf-40kw
 Type HF-40KW
 Work Power  3*380v/415v/440v/480v 50-60hz
 The range of operating voltage  340-430V AC
 Output power  40KW
 Input current  40A
 Fluctuating frequency  30-80khz
 Timing (Heat time,Retain time,Cool time)  1-99S
 The flow rate of cooling water  0.15 Mpa 9L/Min
 Water temperature protection point  40centidegree
 Duty cycle  100% (40degree room temperature)
 Weight  Mainparts:32Kg+28KG
 Size Main Parts:560*230*480mm
Transfromer Part: 460*265*440MM
