Ornamental single double loop wire fence (Factory direct sales)
Ornamental single double loop wire fence (Factory direct sales)
Ornamental single double loop wire fence (Factory direct sales)
Ornamental single double loop wire fence (Factory direct sales)
Ornamental single double loop wire fence (Factory direct sales)
Ornamental single double loop wire fence (Factory direct sales)
Specifications
Brand Name :
LNF-BRC Wire Fence
Model Number :
Top And Bottom Bended
Certification :
ISO
Place of Origin :
American ,Australia ,Canadan
MOQ :
500 liner meter
Price :
16.68$ per liner meter
Payment Terms :
TT30% deposit balance 70% at sight of finished products
Supply Ability :
10000 liner meters
Delivery Time :
7 work days
Packaging Details :
All metal Pallets
Materials :
Q235 steel
Color :
Any Ral Color
Treatment :
Hot Dipped Glavanized,Powder Coated
Mesh Opening :
50mm x 50mm ,55mm x 55mm ,75mm x 75mm ,50mm x 100mm
Diameter :
4.00mm ,5.00mm ,6.00mm
Type :
Weld
Warranty :
5 -25 years depand on the treatment
Main Market :
Europea ,Middle East ,USA ,AU etc
Accessoires :
Clamp and Post Caps etc
Customized :
Available
Feature :
Top And Bottom Circled Design
Application :
Garden Fence, Farm Fence, Residential Fence, Highway Fence, Railway Fence, Balcony Fence, Airport Fence, Stadium Fence, Municipal Fence, Bridge Fence, Stair Fence, Air-Condition Fence, 868 Fence
Trade Mark :
N/M
Sample :
Free but pay freight cost
Top Type :
Round Circle
Nickname :
Double Loop,Double Circled ,Double Ring ,Wire Fence
Description
Double loop wire fence
Basic Info
Model No.:ln-DCF-002
Material: Low Carbon Steel Wire, Metal
Color: Other, Green, Grey, Yellow
Hole Shape: Diamond
Certification: ISO9001
Frame Finishing: Other
Surface Treatment: Galvanized
Weave Technique: Plain Weave
Brand: LNF
Name: Double Circle Fence
Height: 0.5m - 4.0m
Post Spacing: 3.5m Or Less
Wire Diameter: 2.5mm - 5.5mm
Additional Info
Packaging: woden pallet or metal pallet
Productivity: 1000pcs/MONTH
Brand: CAHNGMING
Transportation: Ocean,Land,Air
Place of Origin: Anping, Hebei, China
Supply Ability: 1000pcs/MONTH
Certificate: ISO9001-2008 I90-9001
Port: XINGANG
Product Description
Hot Sale High Quality Double Circle Fence
Double circle fence is welded from cold or hot galvanized Wire, and then bending, spray, or PVC coating to get corrosion resistant, beautiful, and effectively play a protective and so on. Forms of corrosion resistance include electric galvanizing, hot-dipp galvanizing, PVC spraying and PVC coating.
It is normally applied as park fence, private gardens and parks fence, playgrounds fence, plays areas fence, pedestrian zone and public restriction area,factory fencing, residence fencing or house fencing.
Specification
Wire Dia(mm)
Mesh Size(mm)
Length(mm)
Height(mm)
Round Post Size
Surface Treatment
Common Colour
4.0
5.0
6.0
50*100
50*150
50*200
75*200
100*200
100*300
2000
2200
2500
3000
900
48*1.5mm
60*1.5mm
Hot dip galvanized
Electric galvanized then PVC coated
Electric galvanized then powder coating
Green RAL6005
Black RAL9005
White RAL9010
Grey RAL7030
Red RAL3020
Yellow RAL1023
Blue RAL5017
Details
Ornamental single double loop wire fence (Factory direct sales)
Ornamental single double loop wire fence (Factory direct sales)
Ornamental single double loop wire fence (Factory direct sales)
Ornamental single double loop wire fence (Factory direct sales)

1. Features of Double Loop Wire Fence:
  1. Material: Low carbon steel wire, Electric galvanized wire, Stainless steel wire
  2. Surface Treatment: Electro-galvanized, Hot-dipped galvanized, PVC coated, Powder coated
  3. Wire Diameter: 3mm – 6mm as standard
  4. Mesh Size: 50x200mm, 75x150mm, 75x75mm as standard
  5. Panel Length: 1.0m – 3m
  6. Panel Height: 0.5m – 2.5m
  7. Edge can also be bent into the triangle
  8. Applicable Post: Round post

2. Applications of Double Loop Wire Fence:
Widely used for protection of cities, Including gardens, Lawn, Zoos, Pools and lakes, Roads and uptowns, Decoration of hotels and so on.

3. Advantages of Double Loop Wire Fence:
1. Attractive appearance
Different design from a common fence, Round edges make the fence more beautiful and elegant.

2. Built-in rigidity
The rolled beam profile at the top and bottom edge of each panel result in maximum rigidity.

3. Longevity
The polyester coating is able to guarantee longevity. With different colour can make the fence become markedly.

4.User-friendly
Double loop fence is easy to install and dismantle, Friendly top and bottom design, Safety and have low maintenance.

Parameters for quotation:
1). Edge style
2). Wire diameter, mesh opening
3). Fence height, width
4). Surface treatment: electro galvanized, hot-dipped galvanized, PVC coated etc

4. Specification:
Material
High-quality high quality low carbon steel
mesh hole dimension (mm)
75x150,50x200
Length(mm)
1000-2300
Production processing
Drawing, galvanized, welded and then PVC coated
the thickness of dipping (mm)
0.7-0.8
Wire diameter after dipping (mm)
4.0,5.0,6.0
Post style
Round post
Pre-burying base(mm)
500x300x300

5.Process
6.Products
7. Packaging
8. Double loop wire fence application
9. Certificate






Ornamental single double loop wire fence (Factory direct sales)
Ornamental single double loop wire fence (Factory direct sales)Ornamental single double loop wire fence (Factory direct sales)

Ornamental single double loop wire fence (Factory direct sales)
