High-Precision Paper Fold Endurance Tester – ISO/TAPPI Compliant Folding Strength Test Equipment with Servo Motor Drive
High-Precision Paper Fold Endurance Tester – ISO/TAPPI Compliant Folding Strength Test Equipment with Servo Motor Drive
High-Precision Paper Fold Endurance Tester – ISO/TAPPI Compliant Folding Strength Test Equipment with Servo Motor Drive
High-Precision Paper Fold Endurance Tester – ISO/TAPPI Compliant Folding Strength Test Equipment with Servo Motor Drive
Specifications
Brand Name :
HongCe
Model Number :
HC-A519-2
Certification :
Third party calibration certificate(cost additional)
Place of Origin :
China
MOQ :
1 set
Price :
Negotiatable
Payment Terms :
L/C,T/T,D/P
Supply Ability :
10 set for month
Delivery Time :
30 days
Packaging Details :
Plywood
Test Load :
4.9IN, 9.8IN, 14.72N
Specimen Size :
15MM x 150mm, specimen thickness less than 1.25mm
Overall Dimensions :
421*357*526MM
Test Speed :
(175±10)R/MIN (speed can be set arbitrarily from 0-175±10R/MIN)
Folding Head Width :
19+1mm
Folding Chord Radius :
0.38+0.02mm; (replaceable)
Description
Paper Fold Endurance Tester for Packaging and Paper Materials – High-Precision Folding Strength Test Equipment for Quality Control
Product Description

The Paper Fold Endurance Tester from HongCe is designed to help manufacturers, laboratories, and quality-control teams truly understand how durable their paper materials are. Whether you're testing packaging paper, printing paper, banknotes, labels, or specialty materials, this tester delivers reliable folding endurance results with a human-centered experience—stable performance, easy operation, and the accuracy needed for international compliance.

Features
  • High Folding Accuracy – Stable mechanism ensures consistent fold angles and tension force.
  • Long Lifespan & Industrial Design – Built with durable mechanical components for 24/7 continuous testing.
  • Easy-to-Use Interface – Clear layout, ergonomic operation, suitable for both beginners and experienced technicians.
  • Automatic Counting System – Real-time fold cycle tracking with digital display.
  • Wide Material Compatibility – Supports thin paper, kraft paper, coated paper, specialty paper, banknote-grade materials, and more.
International Standards Reference:
  • ISO/TAPPI Paper Folding Endurance Standards
  • ISO 5626 – Paper — Determination of folding endurance
  • TAPPI T511 – Folding endurance of paper (MIT-type)
  • TAPPI T423 – Folding endurance of paper (Schopper method)
Technical Parameters:
Specification Parameter
Drive MethodServo Motor
Test Load4.91N, 9.81N, 14.72N
Bending Angle135°±2° on each side (can be any angle from 135° to 0 to 135°, single-sided and double-sided bending resistance)
Specimen Size15mm*150mm, specimen thickness less than 1.25mm
Test Speed(175±10) r/min (speed can be set arbitrarily from 0 to 175±10 r/min)
Folding Head Width19±1mm
Folding Edge Radius0.38±0.02mm (replaceable)
Folding Head Gap Distance0.25mm/0.5mm/0.75mm/1.0mm (other gaps can be customized)
Counter0~999999 times, automatic stop
Dimensions421*357*526mm (L*W*H)
Display MethodTouchscreen display
WeightApproximately 30KG
Power Supply1∮, 220V, 50HZ, 1A
Total Power ConsumptionApproximately 500W
Main Test ItemFolding Endurance Test of Paper Fiber Materials
Materials & Products That Can Be Tested
Suitable Test Objects:
  • Packaging paper
  • Book paper & notebook paper
  • Currency and security paper
  • Label paper & adhesive paper
  • Kraft paper & corrugated paper
  • Specialty technical paper
Testing Capabilities:
  • Folding endurance
  • Paper fatigue resistance
  • Bending strength
  • Paper aging durability performance
  • Material resistance under cyclic stress
Detailed images:
High-Precision Paper Fold Endurance Tester – ISO/TAPPI Compliant Folding Strength Test Equipment with Servo Motor Drive
FAQ:
1. How long does a typical folding durability test take?

This depends on the paper type and durability rating. Some papers can be tested in minutes, while high-durability materials may take several hours.

2. Can this machine test very thin paper?

Yes. The adjustable clamping system is designed for thin paper, toilet paper, and lightweight specialty materials.

3. Does it comply with ISO 5626?

Fully compliant. This tester fully complies with ISO, TAPPI, ASTM, and GB standards.

4. Is calibration required?

Yes. Calibration ensures data accuracy. Hongce provides calibration guides and optional certified calibration services.

5. Can I run tests continuously for extended periods?

Yes. This machine is designed for stable 24/7 laboratory operation.

6. Is special installation required?

No. Simply connect to a power source to begin testing.
