VDE0620-1 Measuring Gauges For Checking Dimensions Of Germany Plugs And Sockets Made Of Stainless Steel
VDE0620-1 Measuring Gauges For Checking Dimensions Of Germany Plugs And Sockets Made Of Stainless Steel
VDE0620-1 Measuring Gauges For Checking Dimensions Of Germany Plugs And Sockets Made Of Stainless Steel
VDE0620-1 Measuring Gauges For Checking Dimensions Of Germany Plugs And Sockets Made Of Stainless Steel
VDE0620-1 Measuring Gauges For Checking Dimensions Of Germany Plugs And Sockets Made Of Stainless Steel
VDE0620-1 Measuring Gauges For Checking Dimensions Of Germany Plugs And Sockets Made Of Stainless Steel
Specifications
Brand Name :
HongCe
Model Number :
VDE0620-1
Certification :
Calibration certificate (cost additional)
Place of Origin :
China
MOQ :
1 set
Price :
Negotiatable
Payment Terms :
T/T
Supply Ability :
100 set/ month
Delivery Time :
20 Days
Packaging Details :
Aluminum Box
Name :
Measuring Gauge
Standard :
VED0620-1
Test Sample :
Plugs and Sockets
Applicable country :
Germany
Material :
Stainless Steel
Usage :
Checking Dimensions of Plug and Socket
Package :
Plastic tool box
OEM :
yes
Description

VDE0620-1 Gauges For Checking Dimensions of Germany Plugs and Sockets- Made of Stainless Steel

Part of the description from the standard:

18.2 Stecker müssen so gebaut sein, dass sich die Kontaktkraft der seitlichen Schutzkontakte im bestim- mungsgemäßen Gebrauch nicht verschlechtert.
Prüfung: Die seitlichen Schutzkontakte werden mit einer Vorrichtung nach Bild 15 bei einer Umgebungstemperatur von 35 ° C ± 2 ° C mit einer Kraft von 50 N 168 h lang beaufschlagt. Der Angriffspunkt der Vorrichtung muss sich dort befinden wo die Kontaktierung der seitlichen Schutzkontakte bei voll eingestecktem Stecker stattfindet.
Der Schutzkontakt wird 30 s nach dem Zurücknehmen der Kraft gemessen. Die gesamte Änderung der seitlichen Schutzkontakte darf nicht mehr als 1 mm von dem nach Abschnitt 9 festgestellten Istmaß abweichen.

Standard: VDE0620-1.

Application:These gauges are intended to verify and checking the dimensions of plugs and socket-outlets for household and similar purposes. Plug Socket Tester

Test sample:Germany Plugs and socket-outlets for household and similar purposes, and etc.

Feature:Manufacture and operate according to standard requirements. Plug Socket Tester

Item No. Item Name Unit Qty
1 DIN-VDE0620-1-Lehre1 PC 3
2 DIN-VDE0620-1-Lehre2 PC 3
3 DIN-VDE0620-1-Lehre3 PC 1
4 DIN-VDE0620-1-Lehre4 PC 1
5 DIN-VDE0620-1-Lehre5 PC 4
6 DIN-VDE0620-1-Lehre6 PC 2
7 DIN-VDE0620-1-Lehre7 PC 2
8 DIN-VDE0620-1-Lehre8 PC 1
9 DIN-VDE0620-1-Lehre9 PC 1
10 DIN-VDE0620-1-Lehre10A PC 1
11 DIN-VDE0620-1-Lehre10B PC 1
12 DIN-VDE0620-1-Lehre11 PC 1
13 DIN-VDE0620-1-Lehre12 PC 1
14 DIN-VDE0620-1-Lehre13 PC 1
15 DIN-VDE0620-1-Lehre14 PC 1
16 DIN-VDE0620-1-Lehre15 PC 1
17 DIN-VDE0620-1-Lehre16a PC 1
18 DIN-VDE0620-1-Lehre16d PC 1
19 DIN-VDE0620-1-Lehre17 PC 1
20 DIN-VDE0620-1-Lehre18 PC 1
21 DIN-VDE0620-1-Bild15 PC 1
22 DIN-VDE0620-1-Bild14 PC 1
23 DIN-VDE0620-1-Bild43 PC 1
24 DIN-VDE0620-1-16e PC 1
25 DIN-VDE0620-1-19a PC 1
26 DIN-VDE0620-1-19b PC 1
