IEC 62368 Steel Ball Impact Tester 50mm 500g for Luminaires
IEC 62368 Steel Ball Impact Tester 50mm 500g for Luminaires
IEC 62368 Steel Ball Impact Tester 50mm 500g for Luminaires
IEC 62368 Steel Ball Impact Tester 50mm 500g for Luminaires
IEC 62368 Steel Ball Impact Tester 50mm 500g for Luminaires
IEC 62368 Steel Ball Impact Tester 50mm 500g for Luminaires
Specifications
Brand Name :
HongCe
Model Number :
SH-12
Certification :
Calibration certificate(cost additional)
Place of Origin :
China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
10 sets per month
Delivery Time :
30 days
Packaging Details :
plywood
Steel ball diameter :
50mm
Steel ball weight :
500±10g
Drop height :
0.5-1.5m adjustable
Clamping release :
Electronic control
Standard :
IEC 62368-1, IEC 60598-1
Usage :
drop impact test
Test sample :
Luminaries, Audio
Power :
220V
Description
IEC 62368 Steel Ball Impact Tester 50mm 500g for Luminaires
Product Specifications
Attribute Value
Steel ball diameter 50mm
Steel ball weight 500±10g
Drop height 0.5-1.5m adjustable
Clamping release Electronic control
Standard IEC 62368-1, IEC 60598-1
Usage Drop impact test
Test sample Luminaries, Audio
Power 220V
Product Description

IEC 62368 Testing Equipment Steel Ball Impact Test for Enclosure With 50mm Steel Sphere

Compliance Standards
  • IEC 62368-1:2023 Audio/video, information and communication technology equipment - Part 1: Safety requirements clause 4.8.4.5 and clause T.6
  • IEC 60598-1:2020 Luminaires - Part 1: General requirements and tests clause 4.13.4a and figure 21
Application

The steel ball impact test device is a testing instrument that is mainly used to test the mechanical strength of the equipment shell when it withstands foreseeable operations, especially those equipment whose outer surface is damaged and may touch dangerous parts. It can perform two types of tests: vertical drop impact and pendulum horizontal impact.

Test Samples

Luminaries, Audio, video and similar electronic apparatus, Information technology equipment

Key Features
  • Steel ball Diameter: 50mm; Weight: 500g ± 10g
  • Multiple steel ball impact options available to meet different requirements
  • Free-fall test with adjustable drop height (0.5-1.5m)
  • Used for mechanical strength testing of various instrument casings
Technical Parameters
Impact steel ball Diameter 50mm, 500±10g
Drop height 0.5-1.5m adjustable
Lift mode Electric
Clamping release mode Electronic control
