220V 50Hz Ingress Protection Test Equipment For Vertical Drip Rain
220V 50Hz Ingress Protection Test Equipment For Vertical Drip Rain
220V 50Hz Ingress Protection Test Equipment For Vertical Drip Rain
220V 50Hz Ingress Protection Test Equipment For Vertical Drip Rain
Specifications
Brand Name :
KINGPO
MOQ :
1
Certification :
calibration certificate
Place of Origin :
China
Inner box size :
800×800×800mm
Exterior dimension :
1000X1200X1700mm
drip box to test sample :
200mm
power supply :
220V 50Hz
Drip box(mm): :
600X600MM
Testing time :
1-999,999min(can be set)
Description

220V 50Hz Ingress Protection Test Equipment For Vertical Drip Rain

IPX1 And IPX2 Vertical Drip Rain Test Chamber

Standard:IEC60529 degree of protection provided by enclosures (IP Code) of the IPX1 and IPX2, IEC60884-1, IEC60335-1, IEC60598-1.

Application:It is used for the testing of IPX1 and IPX2.

Test sample:The test apparatus with water proof functions, such as electronic appliances, lamps, electrical cabinets, electrical components,car, motorcycle, electrical products (such as automotive instrument, all kinds of switches, micro motors, etc.).

Parameters:

1

Inner box size (mm):800×800×800(L×W×H)( Exterior dimension :1000X1200X1700MM).

2

Rotating speed(rpm):1 ~10 adjustable(IP 1.2 standard. Turntable can be tilted 15°).

3

Drip box(mm): 600X600MM.

4

The distance between the drip box and the test sample:200MM.

5

Needle hole(mm):φ0 .4.

6

Distance between holes(mm):20.

7

Dripping rate (Water flow):1MM or 3MM per minute, adjustable.

8

Testing time:1-999,999min(can be set).

9

The box body is made of square frame, four sides are made of tempered glass.

10

Equipped with a modest turntable (used to place the sample) with adjustable speed, diameter: 500MM.

11

Control system: Independent research and development.

12

Power Supply: 220V 50Hz.

Structural material:

1. High- quality acid -proof stainless steel 304 inner liner.

2. Outer box is made of stainless steel201.

3. The sample table is equipped with a circular turntable with adjustable speed.

Safety protection device:

1.Power overload and short circuit protection.

2. Grounding protection

3. Water shortage protection

4. Alarm buzzer prompts.

220V 50Hz Ingress Protection Test Equipment For Vertical Drip Rain
