Specifications
MOQ :
01 set
Delivery Time :
25 days
Packaging Details :
Nude or Waxed before shipment
Payment Terms :
T/T,L/C
Supply Ability :
100 sets per month
Brand Name :
ISUZU
Description
ISUZU 8x 4 30 Ton Heavy Duty Wrecker Tow Truck

ISUZU 8x4 Drive 30 Ton Heavy Duty Wrecker Tow Truck with 380HP Engine

ISUZU 8x4 Drive 30 Ton Heavy Duty Wrecker Tow Truck with 380HP Engine

ISUZU 8x4 Drive 30 Ton Heavy Duty Wrecker Tow Truck with 380HP Engine

ISUZU 8x4 Drive 30 Ton Heavy Duty Wrecker Tow Truck with 380HP Engine

ISUZU 8x4 Drive 30 Ton Heavy Duty Wrecker Tow Truck with 380HP Engine

Cabin

Driving type 8x4

A/C with one sleeper, 70°hydraulically tillable to the front.

Main Dimensions

Overall dimensions

(L x W x H)mm

12000×2500×3700

Wheel base (mm)

1800+4600+1370

Wheel track (front/rear) (mm)

2022/1830

Weight in KGS

Tare Weight(KGS)

26000

Front axles loading capacity(KGS)

2x7000

Rear axles loading capacity(KGS)

2x16000

Max. driving speed(km/h)

95

Engine

Brand

ISUZU

Model

6UZ1

Type

4-stroke direct injection,6-cylinder in-line with water cooling, turbo-charging and inter-cooling

Horse Power(HP)

380HP

Emission standard

Euro V

Gearbox

Hw19710, 10 speed forward and 2 reverse gear

Clutch

Reinforced diaphragm clutch, diameter 430mm

Steering

ZF8098

Oil tank

400 liters

Tire

12R22.5 tubeless tyre

Special Device For Wrecker System

Hoisting Organ

Rated under-pulling capacity

50000

Max. Under-hoisting Capacity (kg)

25000

Max Under-hoist length (mm)

1850

Under hoisting work angle

-10~85°

Lifting Organ

Max lifting capacity(kg)

40000

Max lifting high(mm)

12000

Telescope length(mm)

6000

Winch

20KN×2

Steel rope

50M,Φ30

Crane luffing angle

5°~ 60°

Crane rotation angle

360°All Rotation

Landing Leg

Distance between front legs(mm)

7000

Distance between rear legs(mm)

4300
