Manufacturer:	Renesas Electronics
Product Category:	Transistor Output Optocouplers
RoHS:
Mounting Style:	SMD/SMT
Package / Case:	SOP-4
Number of Channels:	1 Channel
Isolation Voltage:	3750 Vrms
Output Type:	NPN Phototransistor
Current Transfer Ratio - Min:	50 %
Current Transfer Ratio - Max:	300 %
If - Forward Current:	50 mA
Vf - Forward Voltage:	1.4 V
Maximum Collector Emitter Voltage:	70 V
Maximum Collector Current:	30 mA
Maximum Collector Emitter Saturation Voltage:	300 mV
Rise Time:	5 us
Fall Time:	7 us
Pd - Power Dissipation:	80 mW
Minimum Operating Temperature:	- 55 C
Maximum Operating Temperature:	+ 100 C
Series:	PS2705A-1
Packaging:	Reel
Packaging:	Cut Tape
Packaging:	MouseReel
Brand:	Renesas Electronics
Current Transfer Ratio:	50 %
Height:	mm
Length:	mm
Product Type:	Transistor Output Optocouplers
	3500
Subcategory:	Optocouplers
Width:	mm

PS2705A-1-F3-A Transistor Output Optocouplers NPN Phototransistor Output Type
