potentiometer Amphenol PT15YH06-101A2020-4CR with IP54 protection and up to 100000 cycle lifespan
potentiometer Amphenol PT15YH06-101A2020-4CR with IP54 protection and up to 100000 cycle lifespan
Specifications
Tolerance :
±20%
Power(Watts) :
250mW
Resistance :
100Ω
Description :
100Ω ±20% 250mW Through Hole Potentiometers, Variable Resistors
Mfr. Part # :
PT15YH06-101A2020-4CR
Model Number :
PT15YH06-101A2020-4CR
Package :
Through Hole
Description

Product Overview

The Piher PT-15 and PTC-15 are 15-mm through-hole potentiometers designed for applications requiring frequent adjustment. Featuring a shaftless design, they offer flexibility for various engagement mechanisms like customized shafts, motor controls, or human interface adjustments. These potentiometers are suitable for controlling variable outputs such as frequency, motor speed, or volume. They offer excellent performance with up to 3% linearity, a choice of carbon or cermet resistive elements, and up to 38 mechanical detents for tactile feedback. With a long life of up to 100,000 cycles and IP54 protection, they are ideal for demanding applications.

Product Attributes

  • Brand: Piher
  • Product Series: PT-15 / PTC-15
  • Resistive Element: Carbon or Cermet
  • Mounting Type: Through-hole
  • Protection Rating: IP54
  • Certifications: Self-extinguishable plastic (UL 94V-0) available
  • Packaging: Magazine packaging for automatic insertion available
  • Substrate: Polyester / Alumina
  • Wiper Position Options: Initial, 50%, or fully clockwise
  • Tapers Available: Linear, logarithmic, and antilogarithmic
  • Optional Versions: SPDT switch and low torque versions available

Technical Specifications

Specification PT-15 PTC-15
Taper Lin, Log, Alog Lin, Log, Alog
Range of values 100 Rn 5M 1K Rn 5M
Tolerance (100 Rn 1M) 20% n/a
Tolerance (1M < Rn 5M) 30% n/a
Max. Voltage 250 VDC (Lin) / 125 VDC (Log, Alog) 250 VDC (Lin) / 125 VDC (Log, Alog)
Nominal power @ 50C (122F) 0.25 W (Lin) / 0.12 W (Log, Alog) 0.25 W (Lin) / 0.12 W (Log, Alog)
Nominal power @ 70C (158F) 0.50 W (Lin) / 0.25 W (Log, Alog) 0.50 W (Lin) / 0.25 W (Log, Alog)
Residual resistance 0.5% Rn (5 min.) 0.5% Rn (5 min.)
Equivalent noise resistance 3% Rn (3 min.) 3% Rn (3 min.)
Operating temperature -25C to +70C -40C to +90C
Mechanical rotation angle 265 5 265 5
Electrical rotation angle 240 20 240 20
Torque 0.5 to 2.5 Ncm (0.7 to 3.4 in-oz) 0.5 to 2.5 Ncm (0.7 to 3.4 in-oz)
Rotational Stop > 10 Ncm (>14 in-oz) > 10 Ncm (>14 in-oz)
Life Up to 100k cycles Up to 10k cycles

Applications

  • Appliance program selection
  • Thermostat adjustment
  • Timer and control relays
  • Consumer electronics
  • Power tool controls
  • Test and measurement equipment
