Metallized polypropylene film capacitor Dersonic CFC2J474JE1IL50WA100 with self healing and flame retardant epoxy coating
Metallized polypropylene film capacitor Dersonic CFC2J474JE1IL50WA100 with self healing and flame retardant epoxy coating
Specifications
Capacitance :
470nF
Operating Temperature :
-40℃~+105℃
Tolerance :
±5%
Voltage Rating :
630V
Description :
470nF Film Capacitor ±5% 630V Through Hole P=10mm
Mfr. Part # :
CFC2J474JE1IL50WA100
Model Number :
CFC2J474JE1IL50WA100
Package :
Through Hole,P=10mm
Description

Product Overview

The CBB capacitor is a non-inductive component wound with metallized polypropylene film, featuring tinned copper wire leads and a flame-retardant epoxy resin coating. It offers excellent self-healing properties and flame retardancy, complying with UL 94-V0 standards. This capacitor is ideal for various applications including blocking, coupling, decoupling, filtering, bypassing, timing, and temperature control in communication equipment, data processing devices, industrial instruments, and automatic control systems.

Product Attributes

  • Brand: Dersonic
  • Origin: Dongguan, China
  • Main Materials: Metallized polypropylene film, Zinc/Zinc-tin alloy, Tinned copper clad steel wire/Tinned copper wire, Epoxy resin, Epoxy powder
  • Certifications: UL 94-V0, ROHS, REACH

Technical Specifications

Specification Value Details
Product Code CFC2J474JE1IL50WA100 C2763986
Capacitance 0.47uF Range: 0.001uF~10.0uF
Capacitance Tolerance J (5%) Options: 1%(F), 2%(G), 2.5%(H), 3%(I), 5%(J), 10%(K)
Rated Voltage 630V Options: 100/160/250/400/450/630/1000V
Operating Temperature -40+105 Derating required above 85
Dissipation Factor (tan) 0.10% (C0.47F @ 1KHz) 1KHz: 0.10%, 10KHz: 0.20%, 100KHz: 0.60% (for C0.47F)
Insulation Resistance (IR) 30000MUf (C0.33F) IR100000M (C0.33F)
Lead Pitch (P) 10.0mm Options: 7.5, 10.0, 15.0, 20.0/22.5, 27.5/25.0, 31.5, 41.5
Dimensions (mm) 11.5(W) x 16.5(H) x 7.5(T) W1.0, H1.0, T1.0
Lead Diameter (d) 0.6mm d0.05
Maximum Pulse Rising Gradient (dv/dt) 1500 V/us (for 630V) Varies by rated voltage
Marking Logo, Capacitance (e.g., 104), Tolerance (e.g., J), Rated Voltage (e.g., 400V)

2410121533_Dersonic-CFC2J474JE1IL50WA100_C2763986.pdf
