High Precision 50 SAW Filter Operating at 1090 MHz Model TST TA0970A for Network Analyzers
High Precision 50 SAW Filter Operating at 1090 MHz Model TST TA0970A for Network Analyzers
Specifications
Description :
SMD3838-6P SAW Filters RoHS
Mfr. Part # :
TA0970A
Model Number :
TA0970A
Package :
SMD3838-6P
Description

TA0970A SAW Filter 1090 MHz

This document details the TA0970A, a 50 SAW Filter operating at 1090 MHz, designed for use with HP Network Analyzers. It offers specific electrical characteristics and performance metrics suitable for various RF applications.

Product Attributes

  • Brand: TAI-SAW TECHNOLOGY CO., LTD.
  • Model Number: TA0970A
  • Revision Number: 3.0
  • Origin: Taiwan, R.O.C.
  • Certifications: RoHS Compliant, Lead free
  • Impedance: 50

Technical Specifications

Characteristic Min. Typ. Max. Unit Condition
Center frequency (Fc) - 1090 - MHz -
Insertion loss (IL) - 2.3 3.0 dB within 1075 ~1105 MHz
Amplitude ripple (p-p) - 0.25 0.5 dB within 1085 ~ 1095 MHz
Attenuation (DC ~ 970 MHz) 25.0 30 - dB Reference level from 0 dB
Attenuation (1150 ~ 1300 MHz) 25.0 33.5 - dB Reference level from 0 dB
VSWR - 1.8 2.1 - within 1075 ~1105 MHz
Source impedance (Zs) - 50 - -
Load impedance (ZL) - 50 - -
Temperature Coefficient of Frequency - -36 - ppm/ -

Maximum Ratings

Parameter Rating Unit
Input Power Level 20 dBm
DC voltage 0 V
Operating Temperature -40 to +85 C
Storage Temperature -55 to +85 C

Note: No matching network required for operation at 50 .
