Automotive grade shunt resistor featuring plated sense pins BOURNS CSM2F-7036-L025J20 ideal for battery management systems
Automotive grade shunt resistor featuring plated sense pins BOURNS CSM2F-7036-L025J20 ideal for battery management systems
Specifications
Power(Watts) :
50W
Resistance :
0.025mΩ
Type :
Shunt
Temperature Coefficient :
±100ppm/℃
Tolerance :
±5%
Description :
50W 0.025mΩ Shunt ±100ppm/℃ ±5% Through Hole Specialized Resistors RoHS
Mfr. Part # :
CSM2F-7036-L025J20
Model Number :
CSM2F-7036-L025J20
Package :
Through Hole
Description

Product Overview

The CSM2F-7036 Series is a high-performance shunt resistor featuring sense pins and bare copper terminals. Designed for demanding applications, it offers up to 50 W of permanent power and a high pulse power rating. This RoHS and AEC-Q200 compliant component is ideal for current sensing in battery management systems, hybrid and electric vehicles, bus bars, welding equipment, and frequency converters. Its robust construction and precise electrical characteristics ensure reliable performance in challenging environments.

Product Attributes

  • Brand: Bourns
  • Series: CSM2F-7036
  • Compliance: RoHS Directive 2015/863, AEC-Q200
  • Terminal Material: Bare Copper
  • Surface Finishing: Plated Sense Pins
  • Environmental: Automotive Grade

Technical Specifications

Characteristic Model CSM2F-7036 with Sense Pins Value
Resistance Range / Power Rating @ 125 C CSM2F-7036 25 / 50 W, 50 / 50 W, 100 / 50 W
Operating Temperature Range -40 C ~ +170 C
TCR on Test Points (+20 C to +130 C) 100 ppm/C for 25 ; 50 ppm/C for 50 and 100
TCR Resistance Alloy < 50 ppm/C
Inductance < 5 nH
Resistance Tolerance 5 %
Maximum Fastening Torque 25 Nm
Environmental Characteristics (Test Condition) DTR Max. Thermal Shock (-55 C to +150 C / 1000 cycles) 0.5 %
Environmental Characteristics (Test Condition) High Temperature Exposure (+170 C / 1000 hours) 1.0 %
Environmental Characteristics (Test Condition) Low Temperature Storage (-65 C / 1000 hours) 0.5 %
Environmental Characteristics (Test Condition) Biased Humidity Test (+85 C, 85 % RH, 10 % bias, 1000 hours) 0.5 %
Environmental Characteristics (Test Condition) Mechanical Shock (100 g, 6 milliseconds, 5 pulses) 0.5 %
Environmental Characteristics (Test Condition) Vibration, High Frequency (10-2000 Hz in 1 minute, 3 directions, 12 hours) 0.5 %
Environmental Characteristics (Test Condition) Load Life (+125 C / 2000 hours at maximum current rating) 1.0 %
Solderability* J-STD-002 95 % coverage min. (Limited to dipping terminals and not resistor)
Moisture Sensitivity Level 1
ESD Classification Level 6 per AEC-Q200-002, 25,000 V air discharge
Packaging Tray Pack 20 pcs. per tray, 140 pcs. per box

Product Dimensions

Part Number Dim A (mm/in) Dim B (mm/in) Dim C (mm/in)
CSM2F-7036-L025J20 4.70 (.185) 7.87 (.310)
CSM2F-7036-L050J20 9.40 (.370) 12.57 (.495)
CSM2F-7036-L100J20 20.0 (.787) 23.18 (.913)
CSM2F-7036-L025J30 4.70 (.185) 7.87 (.310) 5.59 (.220)
CSM2F-7036-L050J30 9.40 (.370) 12.57 (.495) 5.59 (.220)
CSM2F-7036-L100J30 20.0 (.787) 23.18 (.913) 5.59 (.220)

How to Order

CSM 2F - 7036 - L050 J 2 0

  • Model: CSM2F-7036
  • No. of Terminals & Style: 2 or 3
  • Size (Metric): 7036
  • Resistance Code (Milliohms): L050 = 50 MicroOhms
  • Resistance Tolerance: J = 5 %
  • Number of Pins: 2 or 3
  • Surface Finishing: 0 = Bare Copper Terminals
