Multi Port Waveguide Directional Coupler / RF Power Combiner 50 Ω Impedance
Multi Port Waveguide Directional Coupler / RF Power Combiner 50 Ω Impedance
Specifications
Brand Name :
ZD
Model Number :
ZD-DC-738-MF
Certification :
RoHS
Place of Origin :
china
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Delivery Time :
3-15 days
Packaging Details :
Standard exporting cartons or as customer required
Product Name :
Waveguide Directional Coupler
3rd Order IMD(dBc) :
≤-120/-140/-150@2X43dBm
Attenuation(698-2700) :
±0.8
Connectors Type :
DIN or N-Female
Impedance(Ω) :
50
Material :
Steel
Description

Multi Port Waveguide Directional Coupler / RF Power Combiner 50 Ω Impedance

Product Description

GSM,CDMA,DCS,3G,WLAN N-Connector Coupler 6dB 800-2500Mhz RF Directional Coupler for cable distribution of radio frequency signals on demand equipment.

We provide 5dB, 7dB, 10dB, 12dB, 15dB, 20dB, 25dB, 30dB, 40dB Directional Coupler in 800~2500M or 700~2700M.

Our Products Features:

  1. Good temperature behavior, High aseismatic capability.
  2. Low Insertion Loss, High power handling.
  3. High quality, Low price
  4. Custom design available upon request.
  5. Meet ROHS standard.
  6. Guaranteed for one year standard
Electrical Specifications:
Coupling(dB) 5 6 7 8 10 12 15 20 25 30 35 40
Attenuation(698-2700) ±0.8 ±1 ±1.2 ±1.2 ±1.2 ±1.5
Insertion Loss(dB) ≤2.1 ≤1.65 ≤1.3 ≤1.1 ≤0.75 ≤0.6 ≤0.4 ≤0.3 ≤0.2 ≤0.2 ≤0.2 ≤0.2
Frequency Range 698-2700MHz
VSWR ≤1.22
Directivity(dB) ≥20 ≥18
Average Power(W) ≤200
3rd Order IMD(dBc) ≤-120/-140/-150@2X43dBm
Connectors Type DIN or N-Female
Operating Temperature(℃) -20~+55
Application For Indoor or Outdoor Use

Our Services

What we could do for you are:
1) factory sell directly
2) long-term,strong and steady supplying ability
3) delivery time: 1-2 working days
4) do as your requirements on package,brand or other designs
5) strong sales promotion policy
6) ex-factory price and competitive price
7) we can provide you a good survice
8) replying you asap.(will reply you 10-20 mins on the basis of getting your require.)

Multi Port Waveguide Directional Coupler / RF Power Combiner 50 Ω Impedance
