High Power Rf Coaxial Connector 4.3-10 Mini Din Male for 1/2 super flexible cable
High Power Rf Coaxial Connector 4.3-10 Mini Din Male for 1/2 super flexible cable
Specifications
Brand Name :
ZD
Model Number :
ZD-CN-MNDM-CF12S
Certification :
RoHS
Place of Origin :
CHINA
MOQ :
Negotiable
Price :
Negotiable
Delivery Time :
5-8 work days
Characteristic Impedance :
50ohm
Insertion Loss :
≤0.12dB@3GHz
Typical Frequency Range :
DC-3GHZ
Type :
4.3-10
Gender :
Male/Jack
VSWR :
≤1.1@-3.0GHz
Description

High Power Rf Coaxial Connector 4.3-10 Mini Din Male for 1/2" super flexible cable

Product Description

Coaxial DIN 4.3-10 to 12 superflexible cable soldering type

ZD RF Connector has an operational frequency range of DC-6 GHz, offers excellent VSWR performance and Low Passive Intermodulation. This makes it ideally suited for use in cellular basestations, distributed antenna systems (DAS) and small cell applications.

Model: ZD-CN-MNDM-CF12S

Description:

4.3-10 Male connector for 1/2’’ Superflexible RF cable

Specification

Material and Plating 　
Center contact Brass / Silver Plating
Insulator PTFE
Body & Outer Conductor Brass / alloy plated with tri-alloy
Gasket Silicon Rubber
Electrical Characteristics 　
Characteristics Impedance 50 Ohm
Frequency Range DC~3 GHz
Insulation Resistance ≥5000MΩ
Dielectric Strength ≥2500 V rms
Center contact resistance ≤1.0 mΩ
Outer contact resistance ≤0.25 mΩ
Insertion Loss ≤0.12dB@3GHz
VSWR ≤1.1@-3.0GHz
Temperature range -40~85℃
PIM dBc(2×20W) ≤-155 dBc(2×20W)
Waterproof IP67

Quick Details

Place of Origin:shenzhen, China (Mainland)
Brand Name:ZD
Model Number:ZD-CN-MNDM-CF12S
Type: 4.3-10
Application:RF
Gender:Male/Jack
Impedance (Ohms):50ohm
