Specifications
Brand Name :
HYUCX
Model Number :
WS08
BAND :
6-8
Power consumption :
≤800W
efficiency :
≥50%
Structural dimensions :
469*385*135mm
Total weight :
16kg
Packaging size :
46.5*43.5*75CM
Packaging weight :
30kg
External control :
Handle control
Description

WS08 Backpack-style Plastic Drone Defense Equipment Specification

Technical parameters

Serial Number

project

Operating frequency

Output power

Remark

1

Channel 1

400MHz～500MHz

47dBm (50W)

Frequency can be customized

Channel 2

500MHz～600MHz

47dBm (50W)

Frequency can be customized

Channel 3

600MHz～800MHz

47dBm (50W)

Frequency can be customized

Channel 4

800MHz～1050MHz

47dBm (50W)

Frequency can be customized

Channel 5

1550MHz～1620MHz

47dBm (50W)

Frequency can be customized

Channel 6

5150MHz～5300MHz

47dBm (50W)

Frequency can be customized

Channel 7

2400MHz～2500MHz

47dBm (50W)

Frequency can be customized

Channel 8

5725MHz～5850MHz

47dBm (50W)

Frequency can be customized

2

Battery capacity and operating time

25AH operates across the entire frequency band for 45 minutes

Portable backpack

3

Power consumption

≤800W

4

efficiency

≥50%

5

Structural dimensions

469*385*135mm

7

Total weight

16kg

8

Packaging size

46.5*43.5*75CM

9

Packaging weight

30kg

10

External control

Handle control

11

interface type

Power interface

Aviation Socket WS20-2

RF interface

NJ impedance 50 ohms

12


antenna

type

Omnidirectional fiberglass antenna + flat panel directional antenna

13

Gain

3±1dBi

15

Power capacity

100W

16

Customers can customize the frequency and power of each frequency band, and can customize 6-channel , 7- channel , and 10 - channel plastic backpacks.
