Photochemical Etching 0.5mm To 5.0mm Heat Exchanger Plate For PCHEs

Description of Heat Exchanger Plates:


What is Printed Circiut Heat Exchangers?


The manufacturing of a printed circuit heat exchanger involves two key technologies: chemical etching and diffusion bonding. Flow channels are precisely etched onto metal plates, which are subsequently stacked and permanently joined through diffusion bonding to create a compact, monolithic unit.


Photochemical Etching 0.5mm To 5.0mm Heat Exchanger Plate For PCHEs Photochemical Etching 0.5mm To 5.0mm Heat Exchanger Plate For PCHEs Photochemical Etching 0.5mm To 5.0mm Heat Exchanger Plate For PCHEs



Specifications of Heat Exchanger Plates:


Material Stainless Steel 316/316L, Aluminum, etc.
Thickness 0.5mm to 5.0mm, or customized
Size Max to 1800*600mm, support customization
General Tolerance ±0.1mm
Processing Photochemical machining/ metal etching/ Photo etching
Other Processing Welding or other processing as requested



Production Process Steps of Heat Exchanger Plates:


1.Chemical etching the channels of heat exchanger plate.

Photochemical Etching 0.5mm To 5.0mm Heat Exchanger Plate For PCHEs


2. Diffusion bonded heat exchangers.


We offer end-to-end solutions for chemical etching and diffusion-bonded printed circuit heat exchangers. With our specialized expertise, we integrate both processes seamlessly to deliver high-quality and efficient results for our customers.



How to custom Heat Exchanger Plate from us?

1. Please send us your design.
We accept the following file formats:DWG, DXF, PDF, STP, Gerber, IGES, CorelDraw and AI.

2. Samples making lead time:3-10days
