380kg Rubber O Ring Flash Trimming Machine from Manufacturing Plant
380kg Rubber O Ring Flash Trimming Machine from Manufacturing Plant
380kg Rubber O Ring Flash Trimming Machine from Manufacturing Plant
380kg Rubber O Ring Flash Trimming Machine from Manufacturing Plant
380kg Rubber O Ring Flash Trimming Machine from Manufacturing Plant
380kg Rubber O Ring Flash Trimming Machine from Manufacturing Plant
380kg Rubber O Ring Flash Trimming Machine from Manufacturing Plant
380kg Rubber O Ring Flash Trimming Machine from Manufacturing Plant
380kg Rubber O Ring Flash Trimming Machine from Manufacturing Plant
380kg Rubber O Ring Flash Trimming Machine from Manufacturing Plant
Specifications
Place of Origin :
China
Brand Name :
Mixer
Type :
Rubber Cutting Machine, PLC
Condition :
New
Video outgoing-inspection :
Provided
Machinery Test Report :
Provided
Warranty of core components :
5 years
Core Components :
PLC, Engine, Bearing, Gear
Voltage :
220V
Dimension(L*W*H) :
1300x640x1000 mm
Warranty :
1 Year
Key Selling Points :
Sustainable
Power (kW) :
4 kW
Weight (KG) :
380 KG
Applicable Industries :
Manufacturing Plant
Showroom Location :
None
Power(W) :
4kw
Weight :
380kg
After-sales Service Provided :
Video technical support
Certification :
CE
Marketing Type :
New Product 2020
Packaging Details :
wooden case package
Port :
Shanghai
Supply Ability :
30sets per months
Price :
$5,000.00 - $9,999.00/sets
MOQ :
1set
Delivery Time :
20-30days
Payment Terms :
T/T
Description
Product Description

Application:

Rubber Oil Seal Trimming machine is used for kinds of rubber skeletons, rubber oil seal, rubber packing cup, kinds of rubber washer, round rubber parts.

Main technical parameter:

Vacuum≤-0.035Mpa

circular run out of main spindle≤0.01mm

plane run out≤0.02mm

Speed of spindle: 0-3000r/min

cutting degree:-10°~100°

cutting range :10mm-300mm (adjustable)

Blade specification(ThickxWidexLength):2x4x75mm

Blade material:tungsten steel.

Total power comsumption: 1 KW

Voltage: 220V,single phase.

Weight: 300kg

Dimension:1020mm×700mm×1300mm

Specification

Main Technical specification:

Motor

4KW (380V,3 Phase,50HZ)

vibrator motor

0.25KW (380V,3 Phase,50HZ)

Compressed air pressure

0.4-0.8 Mpa

Vibrator mesh size

5mm-50mm (customized);standard supply 5 PCS meshes with machine

Working principle

High speed centrifugal tangent technology

Capacity

Equivalent to 30~100 persons’ manual work

Weight

380 kg

Dimension

1300x640x1000 mm
Exhibition

380kg Rubber O Ring Flash Trimming Machine from Manufacturing Plant
