HS Series ISO 14541 Hydraulic Couplings 300–450 Bar Thread-to-Connect Cone Valve Fittings
HS Series ISO 14541 Hydraulic Couplings 300–450 Bar Thread-to-Connect Cone Valve Fittings
Specifications
Brand Name :
carterberg
Model Number :
CB-HS
Certification :
IATF16949
Place of Origin :
China
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Supply Ability :
5000~20000 pc/month
Delivery Time :
7-20 work days
Packaging Details :
carton
Standard :
ISO 14541
Occlusion :
poppet
Locking :
screw
Material :
steel
Finishing :
Zn-Fe(Cr lll)
Threads :
BSP-NPT-SAE
Standard seals :
NBR
Working temperature :
-25℃+100℃
Optional seals :
FKM,EPDM or more
Working pressure :
300-450bar
Description

HS Series ISO 14541 Hydraulic Couplings | 300–450 Bar Thread-to-Connect Cone Valve Fittings


The HS Series ISO 14541 Thread-to-Connect Hydraulic Couplings are designed for high-pressure applications up to 450 bar. Featuring a reliable cone valve system and threaded locking mechanism, they ensure secure, leak-free performance under demanding industrial conditions. Constructed from durable carbon steel with Zn-Fe (Cr III) plating for corrosion resistance, these couplings offer BSP, NPT, and SAE thread options. Standard NBR seals are provided, with FKM and EPDM available for various fluids and temperatures (-25°C to +100°C). Both halves can be connected under residual pressure, making them ideal for agricultural machinery, construction equipment, special vehicles, oil drilling platforms, and metallurgical systems.




Nominal size Working pressure Rated flow(ISO) Max flow rate Burst pressure Fluid spillage
HS ISO Mpa l/min l/min Male(Mpa) Female(Mpa) Coupled(Mpa) cc
04 6.3 45 12 17 190 270 250 0.8
08 10 40 23 46 130 150 180 1.9
10 12.5 40 45 90 126 150 140 2.7
12 19 30 106 190 100 130 140 9.3
20 25 30 189 280 100 130 140 16
25 31.5 30 288 480 100 100 100 30

HS Series ISO 14541 Hydraulic Couplings 300–450 Bar Thread-to-Connect Cone Valve Fittings


Our Services:


1. Customized design, OEM is available.

2. In-time & professional after sales service.

3. Low MOQ, standard package, fast delivery.

4. Special discount and protection are provided to our distributors.

5. As an honest seller, we always use superior raw material, advanced equipments, skilled technicians and strict quality control to ensure our products to be finished in high quality and stable feature.
