Gas Brass 70 Bar Female Pneumatic Quick Coupling
Gas Brass 70 Bar Female Pneumatic Quick Coupling
Gas Brass 70 Bar Female Pneumatic Quick Coupling
Gas Brass 70 Bar Female Pneumatic Quick Coupling
Gas Brass 70 Bar Female Pneumatic Quick Coupling
Gas Brass 70 Bar Female Pneumatic Quick Coupling
Gas Brass 70 Bar Female Pneumatic Quick Coupling
Gas Brass 70 Bar Female Pneumatic Quick Coupling
Specifications
Brand Name :
carterberg
Model Number :
CB-12
Certification :
IATF16949
Place of Origin :
Shanghai, China
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Supply Ability :
5000~20000 pc/month
Delivery Time :
7-20 work days
Packaging Details :
carton
Product name :
Quick Coupler
Type :
Coupling
Pressure :
1000psi
Usage :
Oil Gas Water Industrial
Shape :
Reducing
Connection :
Female
Size :
3/8
Thread :
NPT
Description

3/8'' Nominal Female End Connections pneumatic quick release Brass Pneumatic Quick Coupling

CB12 Series are used compressed air, gases, and liquids.

Standard Materials

  • Brass, zinc-plated steel, stainless steel
  • Seals: NBR, Viton, EPDM

Features

  1. Rugged, reliable
  2. Easy, automatic, push-to-connect design provides instantaneous connection and disconnection of lines, plus automatic shut-off of socket end of line
  3. Compatible with Hansen 4000 Series

Gas Brass 70 Bar Female Pneumatic Quick Coupling

Body Size PARTNO. Thread A B HEX
3/8" CB-S1B-12FN-A 1/8-27 2.10 1.38 0.88
3/8" CB-S2B-12FN-A 1/4-18 2.10 1.38 0.88
3/8" CB-S3B-12FN-A 3/8-18 2.35 1.38 0.88
3/8" CB-S4B-12FN-A 1/2-14 2.62 1.38 1.00

Gas Brass 70 Bar Female Pneumatic Quick Coupling

Body Size PARTNO. Thread C D HEX
3/8" CB-P2S-12FN-A 1/4-18 1.63 0.79 0.69
3/8" CB-P3S-12FN-A 3/8-18 1.81 0.94 0.81
3/8" CB-P4S-12FN-A 1/2-14 2.06 1.15 1.00
3/8" CB-P3B-12FN-A 3/8-18 1.81 0.91 0.81

Our Services:

1. Customized design, OEM is available.
2. In-time & professional after sales service.
3. Low MOQ, standard package, fast delivery.
4. Special discount and protection are provided to our distributors.
5. As an honest seller, we always use superior raw material, advanced equipments, skilled technicians and strict quality control to ensure our products to be finished in high quality and stable feature.
