Rexroth A10VSO45 A10VSO71 A10VSO100 Hydraulic Piston Pump,A10VSO Variable Hydraulic Pump
Rexroth A10VSO45 A10VSO71 A10VSO100 Hydraulic Piston Pump,A10VSO Variable Hydraulic Pump
Specifications
Brand Name :
Rexroth
Model Number :
A10VSO100
Certification :
ISO9001
Place of Origin :
China
MOQ :
1 piece
Price :
USD800 one piece
Payment Terms :
T/T,Western Union
Supply Ability :
100 pieces per day
Delivery Time :
5 days after payment
Description

Rexroth A10VSO45 A10VSO71 A10VSO100 Hydraulic Piston Pump,A10VSO Variable Hydraulic Pump

Axial piston pumps in swash plate and bent axis design are intended for the medium and high pressure range. Numerous variations in the designs, performance ranges and adjustment options offer perfect solutions for mobile and stationary application ranges.

Characteristics

All-purpose medium pressure pump

Size 18…140

Nominal pressure 280 bar

Swashplate design

Open circuit

Through drive for mounting of further pumps up to same size

Low noise

Long service life

Short control response times

Excellent suction characteristics

2 drain ports

Nominal size

18

28

45

71

100

140

Version

Standard

Displacement

Vgmax

cm³

18

28

45

71

100

140

Nominal pressure

pnom

bar

280

280

280

280

280

280

Maximumpressure

pmax

bar

350

350

350

350

350

350

Max.speed1)

atVgmax

nnom

rpm

3300

3000

2600

2200

2000

1800

Flow

atVgmaxand nnom

qVnom

l/min

59

84

117

156

200

252

atVgmaxand n=1500rpm

qV1500

l/min

27

42

68

107

150

210

Power

at qV nomand pnom

P

kW

30

39

55

73

93

118

at qV 1500and pnom

P1500

kW

12.6

20

32

50

70

98

Torque

atVgmaxand pnom

M

Nm

80

125

200

316

445

623

Weight(approx.)

m

kg

12

15

21

33

45

60

Nominal size

45

71

100

140

Version

High speed

Displacement

Vgmax

cm³

45

71

100

140

Nominal pressure

pnom

bar

280

280

280

280

Maximumpressure

pmax

bar

350

350

350

350

Max.speed1)

atVgmax

nnom

rpm

3000

2550

2300

2050

Flow

atVgmaxand nnom

qVnom

l/min

135

178

230

287

atVgmaxand n=1500rpm

qV1500

l/min

68

107

150

210

Power

at qV nomand pnom

P

kW

63

83

107

134

at qV 1500and pnom

P1500

kW

32

50

70

98

Torque

atVgmaxand pnom

M

Nm

200

316

445

623

Weight(approx.)

m

kg

21

33

45

60
