YD11-004A 36" Foldable Mechanic's Creeper Webpage Detail Page (English)

I. Product Specifications (SPECIFICATION)

II. Product Details (PRODUCT DETAILS)

1. Foldable Design Saves Space, 6kg Lightweight for Easy Carrying
   Adopting a single-axis folding structure, folding can be completed with one hand without tool assistance: The unfolded state is a standard creeper size of 910×420×115mm, which can easily slide under the chassis of cars and micro-cars (clearance ≥120mm); after folding, the volume is reduced by 60%, with a thickness of only 35mm, which can be stored in garage corners, car trunks or workshop storage racks. Compared with traditional non-foldable creepers, it saves a lot of storage space. At the same time, the 6kg net weight is equivalent to the weight of a bag of rice, which can be carried by an adult male with one hand, easily moving from the warehouse to the maintenance workstation, adapting to the "multi-station rotation work" scenario.
2. 110kg Load-Bearing Cold-Rolled Steel Plate, Stable Support Against Deformation
   The creeper surface is integrally stamped from 2mm-thick cold-rolled steel plate, paired with a reinforced support frame, with an overall torsional strength of 250N·m and a rated load capacity of 110kg: Even if 20kg pneumatic wrenches, torque wrenches and other tools are placed on the creeper surface during lying, there is no bending or depression; the surface undergoes electrostatic spray-painted anti-rust treatment, and engine oil and gear oil can be wiped clean with a cloth when spilled. No rust occurs in 120-hour salt spray tests, and the service life in humid and oily auto repair environments can reach 5-6 years, which is twice the durability of ordinary thin steel plate creepers.
3. 4 2.5-Inch Swivel Rubber Wheels, Flexible Movement in Small Spaces
   Equipped with 4 2.5-inch high-elastic rubber swivel wheels, which combine smoothness and anti-slip performance: The wheels support 360° omnidirectional rotation, with a minimum turning radius of only 25cm. In narrow spaces such as car chassis (clearance 12-18cm), mechanics can adjust the maintenance position with slight force, and the rolling resistance is ≤35N. Compared with creepers with fixed stands, the movement efficiency is increased by 400%; the non-slip pattern on the outer layer of the rubber wheels enhances friction with the ground, and there is no risk of slipping even on oily workshop floors, ensuring operational safety.
4. Detailed Design for Safety, Adapting to Multi-Scenario Needs

• Anti-Slip Edge Prevents Tool Slipping: The edge of the creeper surface is designed with 1.5cm-high flanging, which can hold common tools such as wrenches and screwdrivers, avoiding tools falling into the vehicle chassis and being difficult to retrieve; the edge of the flanging is smoothly polished to prevent scratching the mechanic's arms;
• Strong Size Adaptability: The 36-inch (910mm) length is suitable for mechanics under 1.75m tall. When lying down, the head to knees can fully fit the creeper surface, avoiding leg cold caused by suspended legs; the 115mm thickness can easily slide under small and medium-sized vehicles such as Volkswagen POLO (chassis clearance 120mm) and Honda Fit (chassis clearance 130mm), with adaptability covering 80% of common family cars.

III. Application Scenarios (APPLICATION SCENARIOS)

1. Car Chassis Maintenance in Auto Repair Shops
   An auto repair shop performs brake system maintenance on a Honda Fit (chassis clearance 130mm), and the mechanic uses the YD11-004A creeper: The folded state is easily carried to the workstation, 4 swivel wheels slide smoothly under the car after unfolding, and the 110kg load capacity stably supports the mechanic and maintenance tools; wrenches are placed on the anti-slip edge to avoid slipping. The maintenance time for a single car is shortened from 70 minutes to 45 minutes, adapting to the "efficient car maintenance" scenario.
2. Daily Vehicle Maintenance in 4S Stores
   A 4S store conducts regular maintenance on a Toyota Corolla (chassis clearance 125mm), and the mechanic uses the YD11-004A creeper: The lightweight design facilitates movement in the workshop, and the swivel wheels roll quietly on the clean floor, enabling comprehensive inspection of chassis components from the front to the rear of the car; after maintenance, it is folded for storage without occupying the maintenance workstation space, adapting to the "efficient maintenance in 4S stores" scenario.
3. DIY Inspection in Home Garages
   A car owner replaces the oil filter for a Wuling Hongguang MINI (chassis clearance 115mm) in his home garage, using the YD11-004A creeper: The 6kg weight is easily taken out of the trunk, slides under the car after unfolding, and the swivel wheels help accurately align with the oil filter position; accessories are placed on the anti-slip edge to avoid loss, and DIY inspection can be completed without professional equipment, adapting to the "convenient home DIY operation" scenario.
4. Maintenance of Small Construction Machinery
   An engineering team repairs the fuel pipeline of a small generator (chassis clearance 140mm), and the mechanic uses the YD11-004A creeper: The cold-rolled steel creeper surface resists dust around the generator, the swivel wheels move flexibly on the concrete floor, and easily approach the fault point; the 110kg load capacity bears the mechanic and inspection tools, ensuring maintenance accuracy, adapting to the "small equipment maintenance" scenario.

IV. Frequently Asked Questions (FAQ)

Q1: With a 110kg load capacity, can it support a 100kg mechanic working with 15kg tools?

Q2: The folding hinge becomes loose after a period of use. How to handle it?

Q3: With a weight of 6kg, can female users carry it alone from the garage to the vehicle (10 meters away)?

Q4: When used on concrete ground with small gravel (diameter ≤8mm), will the wheels be stuck?
