12 Ton Capacity Pin Type Jack Stand with Safety Pin and Angled Teeth Post Lock and Large Saddle Surface Area
12 Ton Capacity Pin Type Jack Stand with Safety Pin and Angled Teeth Post Lock and Large Saddle Surface Area
12 Ton Capacity Pin Type Jack Stand with Safety Pin and Angled Teeth Post Lock and Large Saddle Surface Area
12 Ton Capacity Pin Type Jack Stand with Safety Pin and Angled Teeth Post Lock and Large Saddle Surface Area
Specifications
Model Number :
YD13-019
Model :
YD13-019
Supply Ability :
500PCS/MONTH
Base/Post Material :
Welded Steel Plate Base, Cast Iron Support Post
Delivery Time :
30-45DAYS
Size / Dimensions :
480 x 480 x 780 mm / 16.5 x 16.5 x 31.5–47.2"
MOQ :
50pcs
Packaging Details :
Carton Box or Crate
Safety Feature :
Safety Pin, Angled Teeth Post Lock
Payment Terms :
T/T
Saddle :
Large Saddle Surface Area
Brand Name :
YEEDA
Product Name :
12 Ton Pin Type Jack Stand YD13-019
Certification :
CE
Type :
Pin Type Jack Stand / Ratchet Axle Stand
Place of Origin :
Zhejiang，China
Capacity :
12 Ton
Description
12 Ton Pin Type Jack Stand YD13-019 Ratchet Axle Stand with Safety Pin
12 Ton Capacity Pin Type Jack Stand with Safety Pin and Angled Teeth Post Lock and Large Saddle Surface Area

This 12 ton pin type jack stand is built for garage and workshop vehicle support. Model YD13-019 is a ratchet type axle stand with a cast iron support post and a tough welded steel plate base. It uses a safety pin and angled teeth in the post to prevent accidental release of load — the more weight applied, the tighter the post is locked. The large saddle surface area provides better contact with the load being supported.

Dimensions from the image: max height 47.2" / 1200mm, working/stand height reference 31.5" / 800mm, base spread 16.5" / 420mm by 16.5" / 420mm. Specification: size 480 x 480 x 780mm, G.W. 52.9LBS / 24KG, N.W. 48.5LBS / 22KG.

Product Parameters
Item Specification
Model YD13-019
Product Name 12 Ton Pin Type Jack Stand
Type Pin Type / Ratchet Axle Stand
Capacity 12 Ton
Max Height 47.2" / 1200mm
Height Reference 31.5" / 800mm
Base Spread 16.5" / 420mm x 16.5" / 420mm
Size 480 x 480 x 780mm
Saddle Large Saddle Surface Area
Post Cast Iron Support Post with Angled Teeth
Base Welded Steel Plate Base
Safety Safety Pin
G.W. 52.9LBS / 24KG
N.W. 48.5LBS / 22KG
Application Garage Vehicle Support
Key Features
  • 12 ton pin type jack stand for vehicle support
  • Ratchet type axle stand with cast iron support post
  • Tough welded steel plate base
  • Large saddle surface area for better load contact
  • Safety pin and angled teeth post to prevent accidental load release
  • Locking tightens as more weight is applied
  • Suitable for garage and workshop use
Application

This 12 ton pin type jack stand is suitable for garages and workshops when supporting vehicles during maintenance or repair. The pin lock, angled teeth post, large saddle, and welded steel base help provide stable support.

Product Questions and Answers
What is the model and capacity?
Model YD13-019, 12 ton capacity.
What type of jack stand is it?
Pin type jack stand / ratchet type axle stand.
What safety features are shown?
Safety pin and angled teeth in the post to prevent accidental release of load; the more weight applied, the tighter the post is locked.
What is the saddle feature?
Large saddle surface area provides better contact with the load being supported.
What materials are used?
Cast iron support post and welded steel plate base.
What are the dimensions?
Max height 47.2" / 1200mm, height reference 31.5" / 800mm, base 16.5" / 420mm x 16.5" / 420mm. Size 480 x 480 x 780mm.
What is the weight?
G.W. 52.9LBS / 24KG, N.W. 48.5LBS / 22KG.
Where is it used?
Garages and workshops for vehicle support.
