Specifications
Product Name :
OEM Solutions
Key Word :
Solutions
Product Type :
1SW/B Wire Braided Steam Hose, Fluid Hose OEM Solutions
Reinforcement Structure :
1 Layer of Steel Wire Braid
Working Pressure :
20 Bar / 290 PSI
Temperature Range :
-40℃ to +210℃ (intermittent +230℃)
Material :
EPDM Rubber (Inner & Outer Layer)
Applicable Standards :
BS 5342 Type-2, EN ISO 10655
Description
Steam Hose 1sw/b Wire Braided Fluid Hose Your Hose Oem Solutions
OEM Solutions product introduction

This is 1SW/B Wire Braided Steam Hose, a high-performance fluid hose from JDE, providing professional hose OEM solutions for global customers.
The hose features a black EPDM rubber inner layer resistant to saturated steam, 1 layer of high-tensile steel wire braid reinforcement, and a red EPDM outer cover with excellent ozone and weather resistance. It supports a working pressure of 20 Bar / 290 PSI, with a wide temperature range from -40℃ to +210℃ (intermittent up to +230℃), making it ideal for high-temperature steam lines and hot liquid transport.
We offer full OEM/ODM customization services, including customized sizes, lengths, fittings, and brand logos, to meet the specific needs of different industrial scenarios. All products are certified by MSHA, BV, GOST, IATF 16949, ISO 9001, etc., ensuring reliable quality and compliance with international standards.

OME Solutions product Specification

Part Number Hose Size I.D. R.O.D. O.D. Operating Pressure Burst Pressure Bend Radius Weight Length Per PCS Ferrule
I.D. Dash Size mm inch mm mm mm bar psi bar psi mm kgs/m meter DMECode
KON 713101-10 -06 9.5 3/8'' 9.3-10.1 14.5-15.7 18.1 MAX. 20 290 80 1160 130 0.390 50/100 DPF2T-06
KON 713101-12 -08 12.7 1/2'' 12.3-13.5 17.5-19.1 21.4 MAX. 20 290 80 1160 180 0.472 50/100 DPF2T-08
KON 713101-16 -10 16.0 5/8'' 15.5-16.7 20.6-22.2 24.5 MAX. 20 290 80 1160 200 0.581 50/100 DPF2T-10
KON 713101-19 -12 19.0 3/4'' 18.6-19.8 24.6-26.2 28.5 MAX. 20 290 80 1160 240 0.690 50/100 DPF2T-12
KON 713101-25 -16 25.4 1'' 25.0-26.4 32.5-34.1 36.6 MAX. 20 290 80 1160 300 0.830 50/100 DPF2T-16
KON 713101-32 -20 31.8 1-1/4'' 31.4-33.0 39.3-41.7 44.8 MAX. 20 290 80 1160 420 1.325 20/40 DPF2T-20
KON 713101-38 -24 38.1 1-1/2'' 37.7-39.3 45.6-48.0 52.1 MAX. 20 290 80 1160 500 1.500 20/40 DPF2T-24
KON 713101-51 -32 50.8 2'' 50.4-52.0 58.7-61.7 65.5 MAX. 20 290 80 1160 630 1.875 20/40 DPF2T-32

OME Solutions Product Advantages

High Temperature Resistance: Excellent performance in high-temperature steam lines up to +210℃ (intermittent +230℃), suitable for extreme temperature environments.
Superior Pressure Capacity: 1 layer of steel wire braid reinforcement ensures a stable working pressure of 20 Bar / 290 PSI, safe and reliable.
Excellent Material Performance: EPDM rubber inner and outer layers, resistant to saturated steam, ozone, weather and aging, extending service life.
Full OEM Solutions: Provide customized size, length, fitting, and brand logo services to meet personalized customer needs.
International Standard Compliance: Certified by multiple international authorities (MSHA, BV, ISO, etc.), meeting BS 5342 Type-2 and EN ISO 10655 standards.
Wide Application: Suitable for water, heated steam and other high-temperature fluid transport, widely used in industrial, mechanical and other fields.
