Cold Drawn Grind Surface 1.3813 Forged Steel Bar
Cold Drawn Grind Surface 1.3813 Forged Steel Bar
Cold Drawn Grind Surface 1.3813 Forged Steel Bar
Cold Drawn Grind Surface 1.3813 Forged Steel Bar
Specifications
Brand Name :
UST
Model Number :
X40MnCrN19/X40MnCrN19K/1.3813
Certification :
ISO
Place of Origin :
CHINA
MOQ :
MOQ3-5 TONS
Payment Terms :
L/C, T/T
Supply Ability :
800 ton/month
Delivery Time :
Within 5-8 weeks
Packaging Details :
Plastic plugs in both ends, Hexagonal bundles of max 2,000kg with several steel strips, Two tags on each bundle, Wrapped in waterproof paper, PVC sleeve, and sackcloth with several steel strips.
Alloy or not :
Is Alloy
Steel grade :
Alloy Steel X40MnCrN19/X40MnCrN19K/1.3813
Delivery condition :
Hot Forged +Rough Machined (black Surface,Finish Machining,forged +Rough machined (black surface after Q/T)+ Turned (optional),Hot Forged +A/N/QT
Diameter :
12mm - 500mm
Tolerance :
+_0.1MM,H9 or K11,0/+1mm,0/+2mm for size
model :
X40MnCrN19/X40MnCrN19K/1.3813
Description

X40MnCrN19/X40MnCrN19K/1.3813 Cold Drawn Steel Bars

Produt Details


Spec. EN 10308, EN 10228-2, EN 10204
The bars can either be rolled or forged provided that the requested mechanical properties in cold drawn condition are fulfilled.

Chemical Composition(Heat analysis in weight/%)

c

Si

Mn

P

s

Cr

N

0,30-0,50

<0,50

18,0-20,0

<0,050

<0,015

3,00-5,00

0,080-0,120


Mechanical Properties
A hardness test shall be performed to verify the uniformity of the strength within a delivery lot (permelt and heat treatment batch).
The test amount shall be 10 % of the bars with a minimum of 10 bars. When the lot consists of less than 10 bars all bars shall be tested.
The mechanical properties are to be determined for both the hardest and softest bar.


0.2%-proof strength


tensile strength


elongation


reduction of area


impact energy


hardness

10 =5d

(N/mm2)

(N/mm2)

(%)

(%)

(J)

HB30

>500

850-1250

>20

>35

S901’

260 - 360
