DIN 17230 / 100 CrMo7-3 Bearing Steel Bar For Anti Friction Size 10-350 Mm
DIN 17230 / 100 CrMo7-3 Bearing Steel Bar For Anti Friction Size 10-350 Mm
DIN 17230 / 100 CrMo7-3 Bearing Steel Bar For Anti Friction Size 10-350 Mm
DIN 17230 / 100 CrMo7-3 Bearing Steel Bar For Anti Friction Size 10-350 Mm
DIN 17230 / 100 CrMo7-3 Bearing Steel Bar For Anti Friction Size 10-350 Mm
DIN 17230 / 100 CrMo7-3 Bearing Steel Bar For Anti Friction Size 10-350 Mm
DIN 17230 / 100 CrMo7-3 Bearing Steel Bar For Anti Friction Size 10-350 Mm
DIN 17230 / 100 CrMo7-3 Bearing Steel Bar For Anti Friction Size 10-350 Mm
Specifications
Brand Name :
Unite Steel
Model Number :
Dia: 10-350mm
Certification :
MTC/ISO/BV/SGS
Place of Origin :
China
MOQ :
MOQ:2-3 Ton
Price :
USD 600-1000 Ton
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
3000 Ton per Month
Delivery Time :
Within 15-45 days
Packaging Details :
Standard seaworthy packing or as your request .
Product name :
DIN 17230 100CrMo7-3 Bearing Steel Bar , Anti Friction Steel Bar, Size 10-350mm , Low MOQ
Material grade :
100CrMo7-3, 100CrMo7, SUJ5, 52100Mod.3, GCr18Mo
Delivery condition :
Annealed/hot rolled/cold draw/quenched & tempered
Surface :
Black/machined/peeled/polished/turned
Shape :
Round section
Process :
AF+LF+VOD+Rolled/Forged+Heat Treatment(optional)
Ultrasonic test :
According to SEP 1921-84
Length :
as your request
Description

DIN 17230 100CrMo7-3 Bearing Steel Bar , Anti Friction Steel Bar, Size 10-350mm , Low MOQ

Applications: Anti Friction Steel Bar 100CrMo7-3 used in Bearings, shaft, auto, machinery and equipment, etc.

DIN 17230 / 100 CrMo7-3 Bearing Steel Bar For Anti Friction Size 10-350 Mm

Equivalent Grades:

Standard GB/T 18254 CNS3014 ISO 683/17 JIS G4805 DIN 17230 ASTM A535 NF A35 -565
Grade GCr18Mo SUJ5 100CrMo7 SUJ5 100CrMo7-3 52100Mod.3 100CrMo7-3

Chemical Composition:

100CrMo7-3 C Si Mn P S
% 0.93-1.05 0.15-0.35 0.25-0.45 ≤0.020 ≤0.01
100CrMo7-3 Cr Mo Al Cu O
% 1.65-1.95 0.15-0.30 ≤0.050 ≤0.30 ≤0.015

Process:

EAF+LF+VOD+ Hot Rolled/forged+Cut+Heat Treatment(optional)+UT+package.

DIN 17230 / 100 CrMo7-3 Bearing Steel Bar For Anti Friction Size 10-350 Mm

Size Range:

Dia: Cold drawn: 2.5-80 mm, Hot Rolled: 6.5mm-300mm, Hot forged: 150-800 mm.

Length: Not more than 12 m.

Delivery Condition:

Cold drawn, Hot rolled, Hot forged,Heat treatment.

Surface:

Black, Peeled (K12), Turned & Polished (H10, H11), Precision Ground (H9, H8).

Ultrasonic Test:

According to SEP 1921-84

DIN 17230 / 100 CrMo7-3 Bearing Steel Bar For Anti Friction Size 10-350 Mm

High Wear Resistant Steel Bar 100CrMo7-3 Features:

1. Cleanliness and freedom from objectionable microscopic slag type inclusions.

2. Shallow decarburized surface.

3. Good surface quality.

4. Excellent micro-structure uniformity.

5. Tight tolerances, resulting in reduced machine time.

6. Wear resistance, long service life.
