1020 / C22 / 1.0402 / S20C Honed Stainless Steel Tubing For Hydraulic Cylinder
1020 / C22 / 1.0402 / S20C Honed Stainless Steel Tubing For Hydraulic Cylinder
1020 / C22 / 1.0402 / S20C Honed Stainless Steel Tubing For Hydraulic Cylinder
1020 / C22 / 1.0402 / S20C Honed Stainless Steel Tubing For Hydraulic Cylinder
1020 / C22 / 1.0402 / S20C Honed Stainless Steel Tubing For Hydraulic Cylinder
1020 / C22 / 1.0402 / S20C Honed Stainless Steel Tubing For Hydraulic Cylinder
1020 / C22 / 1.0402 / S20C Honed Stainless Steel Tubing For Hydraulic Cylinder
1020 / C22 / 1.0402 / S20C Honed Stainless Steel Tubing For Hydraulic Cylinder
Specifications
Brand Name :
UST
Model Number :
OD: 30-450mm; WT: 2-40mm
Certification :
ISO 9001
Place of Origin :
China
MOQ :
MOQ: 2-3 ton
Price :
USD 800- 1500/ton
Supply Ability :
1000 ton/month
Delivery Time :
Within 5-35 days
Packaging Details :
Plastic plugs in both ends, Hexagonal bundles of max 2,000kg with several steel strips, Two tags on each bundle, Wrapped in waterproof paper, PVC sleeve, and sackcloth with several steel strips.
Usage :
Hydraulic Cylinder
Production Technique :
Honing/skiving tube
Quality Standard :
DIN 2391, EN10305
Surface :
Black, Bright, Smooth
Delivery Condition :
BKS, NBK,BK ,BKW, GBK(+A), NBK(+N), BK(+C)
Product name :
Carbon steel tube 1020/C22/1.0402/S20C
Inspection :
The third party is acceptable
End protector: :
Plastic Pipe Cap
Marking :
Request
Description

1020/C22/1.0402/S20C Hydraulic Cylinder Steel Tube honing pipes and skiving pipes

honing/skiving tube has closer dimensional tolerances, better surface finish and higher mechanical properties than corresponding grades of hot finished seamless.

Application

High Precision Cold Drawned Seamless Steel Tube is used in automotive industry, and in the occasion where the high accuracy, brightness, cleanness of the tube are required.

1. Quality Standards:

DIN 2391 Seamless Precison Steel Tubes

BS6323 Specification for Seamless and Welded Steel Tubes for Automobile, Mechanical and General Engineering Purposes

ASTM A519 Standard Specification for Seamless Carbon and Alloy Steel Mechanical Tubing

2. Delivery Condition: BKS, NBK, BK and BKW

Outer Diameter: 30-450 mm

Wall Thickness: 2-40 mm

Length Random Length, Fixed Length, etc.

3. Dimension tolerance:

I.D tolerance (mm) O.D tolerance (mm) I.D Roughness (µm) Straightness (mm/meter)
H7-H9 -/+0.5% 0.10-0.80 0.2-0.80

4. Chemical Composition(%):

Grade C Si Mn P S Cr Mo
1020 0.18-0.25 / 0.30-0.60 0.040 max 0.050 max / /

5. Our Services

Third Party inspection acceptable. such as SGS, BV etc.

Supplying financial support with usance L/C 180 days after B/L date.

6.Our Advantages

1) Fast delivery
2) Non-standard sizes and made-to-order
3) Small min order quantity
4) Economical Pricing
5) Quality confirming to International Standards
6) Material Test Certificates for Quality Assurance
7) Technical Qualified After Sales
8) Excellent Delivery Conditions

1020 / C22 / 1.0402 / S20C Honed Stainless Steel Tubing For Hydraulic Cylinder

1020 / C22 / 1.0402 / S20C Honed Stainless Steel Tubing For Hydraulic Cylinder

Please feel free to contact us again if you have any further questions. We look forward to receiving an order from you.
