Honed Hydraulic Cylinder Steel Tube 4140 / SCM440 / 42CrMo4 / 42CrMo Alloy Steel
Honed Hydraulic Cylinder Steel Tube 4140 / SCM440 / 42CrMo4 / 42CrMo Alloy Steel
Honed Hydraulic Cylinder Steel Tube 4140 / SCM440 / 42CrMo4 / 42CrMo Alloy Steel
Honed Hydraulic Cylinder Steel Tube 4140 / SCM440 / 42CrMo4 / 42CrMo Alloy Steel
Honed Hydraulic Cylinder Steel Tube 4140 / SCM440 / 42CrMo4 / 42CrMo Alloy Steel
Honed Hydraulic Cylinder Steel Tube 4140 / SCM440 / 42CrMo4 / 42CrMo Alloy Steel
Honed Hydraulic Cylinder Steel Tube 4140 / SCM440 / 42CrMo4 / 42CrMo Alloy Steel
Honed Hydraulic Cylinder Steel Tube 4140 / SCM440 / 42CrMo4 / 42CrMo Alloy Steel
Specifications
Brand Name :
UST
Model Number :
OD: 30-450mm; WT: 2-40mm
Certification :
ISO 9001
Place of Origin :
China
MOQ :
MOQ: 2-3 ton
Price :
USD 800- 1500/ton
Supply Ability :
1000 ton/month
Delivery Time :
Within 5-35 days
Packaging Details :
Plastic plugs in both ends, Hexagonal bundles of max 2,000kg with several steel strips, Two tags on each bundle, Wrapped in waterproof paper, PVC sleeve, and sackcloth with several steel strips.
Usage :
Hydraulic Cylinder
Production Technique :
Honing/skiving tube
Quality Standard :
DIN 2391, EN10305
Surface :
Black, Bright, Smooth
Delivery Condition :
BKS, NBK,BK ,BKW, GBK(+A), NBK(+N), BK(+C)
Product name :
Alloy steel 4140/SCM440/42CrMo4/42CrMo
Inspection :
The third party is acceptable
Description

4140/SCM440/42CrMo4/42CrMo Hydraulic Cylinder Steel Tube honing pipe and skiving pipe

Standard: DIN2391, EN 10305, JIS G3445, ASTM A519, GB/T 8713…

Material: ST45, ST52, E355, E355SR, STKM13C, SAE 1026, 20#, Q235B, CK45…

Heat treatment: BK+S

Specification: Out diameter: 20-800mm, Inner diameter: 40-250mm

I.D Tolerance: H8-H9

Length: 1-12m(Customers usually choose the 4-5.8m)

Straightness: 1/1000

ID roughness: RA 0.4micron(max)

Technology: Honed & SRB( Skived and roller Burnished)

Scope: Honed tube for hydraulic cylinder, swivel crane, injection machine and construction machine application

Chemical Composition
C Si Mn P S Cr Mo
0.38-0.43 0.15-0.35 0.75-1.00 0.040max 0.040max 0.80-1.10 0.15-0.25

Honed Hydraulic Cylinder Steel Tube 4140 / SCM440 / 42CrMo4 / 42CrMo Alloy Steel

Please feel free to contact us again if you have any further questions. We look forward to receiving an order from you.
