Specifications
Brand Name :
Unite Steel
Model Number :
Dia: 10-320mmm
Certification :
ISO/MTC/BV/SGS
Place of Origin :
China
MOQ :
MOQ :2-3 Ton
Price :
USD 700-1200 per Ton
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
3000 Ton per Month
Delivery Time :
Within 15-45 days
Packaging Details :
Stanard seaworthy packing or as your request .
Product name :
DIN 1.6660/20NiCrMo13-4 Hot Rolled Steel Bar , Alloy Steel Round Bar With QT
Material grade :
20NiCrMo13-4/1.6660
Delievry condition :
Annealed/hot rolled/cold drawn/quenched & tempered
Surface :
Black/machined/peeled/polished/turned
Shape :
Round section
Process :
EAF+LF+VOD+Rolled+Heat Treatment(optional)
Ultrasonic inspection :
100% ultrasonic inspection for any inperfections or based on the customer's requirement
Certificate :
ISO/MTC/BV/SGS
Description

DIN 1.6660/20NiCrMo13-4 Hot Rolled Steel Bar , Alloy Steel Round Bar With QT

Grade : 20NiCrMo13-4
Number: 1.6660
Standard: EN 10084 : 2008 Case hardening steels. Technical delivery conditions
Classification: Case hardening steels


Chemical composition % of the ladle analysis of grade 20NiCrMo13-4 (1.6660)

Elements not quoted in this table shall not be intentionally added to the steel without the agreement of the purchaser, other than for the purpose of finishing the heat.
Steels with improved machinability as a result of the addition of lead or higher sulfur contents, depending on the manufacturing process up to around 0.1 % S, may be supplied on request. In this case, the upper limit of the manganese content may be increased by 0.15 %

C Si Mn Ni P S Cr Mo
0.17 - 0.22 max 0.4 0.3 - 0.6 3 - 3.5 max 0.025 max 0.035 0.8 - 1.2 0.3 - 0.5

Products Introduction:

Specifications

Round bar:
Diameter : 1mm-2000mm

Plate steel/flat bar:
Size: Thickness: 0.1mm-800mm Width: 10mm to 1500mm

Hot-rolled sheet: Thickness:6-80mm Width: 210-610mm

Length: We can supply any length based on the customer's requirement.

Forging: Shafts with flanks/pipes/tubes/slugs/donuts/cubes/other shapes

Finished goods condition: hot forging/hot rolling + annealing/normalizing + tempering/quenching + tempering/any conditions based on the customer's requirement

Surface conditions: scaled (hot working finish)/ground/rough machining/fine machining/based on the customer's requirement

Furnaces for metallurgical processing: electrode arc + LF/VD/VOD/ESR/Vacuum consumable electrode.

Ultrasonic inspection: 100% ultrasonic inspection for any inperfections or based on the customer's requirement.
