6.1 Inch Chisel Hydraulic Excavator Breaker 1.2 Inch Hydraulic Jack Hammer Crushing
6.1 Inch Chisel Hydraulic Excavator Breaker 1.2 Inch Hydraulic Jack Hammer Crushing
Specifications
Brand Name :
HANYUN
Model Number :
155mm chisels
Certification :
CE/ISO
Place of Origin :
CHINA
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, , T/T, D/A, D/P
Supply Ability :
5000 sets per year
Delivery Time :
3-30 working days
Packaging Details :
Exported packages/fumigation-free plywood box
Item :
Hydraulic Jack Hammers For Excavator
Breaker chisel diameter :
155mm/6.1 inch
Raw materials :
Anti-resistance steel
Soft hose diameter :
1.2 inch
Size :
Customized size
Color :
Blue, red, green, yellow or other colors
Vehicle mounted :
Hydraulic excavator, loader, backhoe and skid steer
Technical support :
Online support, video support
Description

Hydraulic Excavator Crushing Breaker Hydraulic Jack Hammers For Excavator

(1) Main technical parameters on hydraulic excavator crushing breaker

Model HY135 HY140 HY155
Breaker shell weight (KGS) 600 800 1450
Total weight(KG) 1663 1700 2635
Size (MM) 1610*530*1280 166*530*1280 1900*635*1350
Driving oil pressure (KG/CM2) 180-220 190-230 230-260
Hydraulic oil flow (L/MIN) 100-150 120-180 180-240
Striking frequency (BPM) 350-600 350-500 300-450
Soft hose diameter (INCH) 1 1 1.2
Drill rod diameter (MM) 135 140 155
Drill rod weight (KG) 125 130 190
Applicable carrier weight (T) 18-23 19-25 25-30

(Different size and types could also be customized to suit different demands)

(2) Standard details on 155mm hydraulic excavator crushing breaker

Model: HYQG155

Breaker chisel diameter: 155mm

Breaker chisel length: 1500mm

Weight: 190KGS

Applicable vehicle weight: 30t

(3) Main details on front head and back head of breaker main body

Front head SB121 765*288*326MM
Back head SB121 375*288*383MM
Hydraulic breaker piston 170(-0.07)*173.5(-0.06)*157(0.06)MM /Total length 930MM

6.1 Inch Chisel Hydraulic Excavator Breaker 1.2 Inch Hydraulic Jack Hammer Crushing
