Concrete Hydraulic Plate Compactor 6.5ton Impulse Power CE Approved
Concrete Hydraulic Plate Compactor 6.5ton Impulse Power CE Approved
Specifications
Brand Name :
Wakestone
Model Number :
Wakestone
CertifiC-A-Tion :
ISO
Place of Origin :
CHINA
Payment Terms :
L/C, T/T
Delivery Time :
8-10 workdays
MOQ :
1.00
Packaging Details :
Standard export package
AppliC-A-Tion :
Construction, Excavaotor
Power of Impulse :
6.5 ton
Vibration Frequency :
2000 rpm/min
Oil Flow :
45-85 l/min
Operating Pressure :
100-130 kg/cm2
Weight :
550-600 kg
Carrier Weight :
12-16 ton
Description

CE Approved Excavator Hydraulic Vibro Concrete Compactor

Features:

1. High quality hoses without leakage
2. Wide range of mounting options are avaliable for pinon, skid steer or quick coupler configurations
3. Damping rubber to be lasting and durable.

Model
Unit
YGC-02
YGC-06
YGC-08
YGC-10
Suitable carrier
ton
4-8
12-18
19-24
25-32
Pin Diameter
mm
45/50
60/65
70/80
90
Impact force
ton
4
6.5
15
15
Max. Number for Vibration
rpm
2000
2000
2000
2000
Oil flow
l/min
45-75
85-105
120-170
120-170
Pressure
Kg/cm2
100-130
100-130
150-200
150-200
Weight
Kg
400
750
1000
1100
Impact size (LxWxT)
mm
900x550x25
1160x700x28
1350x900x30
1350x900x30
Total height
mm
760
920
1060
1100
Total width
mm
550
700
900
900

Concrete Hydraulic Plate Compactor 6.5ton Impulse Power CE ApprovedConcrete Hydraulic Plate Compactor 6.5ton Impulse Power CE Approved
