OEM MS700 Full Hydraulic System Breaker Hammer For 25-35 Ton Excavators With 400-500 Bpm Impact Rate
OEM MS700 Full Hydraulic System Breaker Hammer For 25-35 Ton Excavators With 400-500 Bpm Impact Rate
OEM MS700 Full Hydraulic System Breaker Hammer For 25-35 Ton Excavators With 400-500 Bpm Impact Rate
OEM MS700 Full Hydraulic System Breaker Hammer For 25-35 Ton Excavators With 400-500 Bpm Impact Rate
Specifications
Brand Name :
SEWOOMIC
Model Number :
MS700/GHB230/GHB140
Certification :
CE,ISO 9001
Place of Origin :
Jiangsu, China
MOQ :
1 piece
Price :
Negotiable
Payment Terms :
L/C,T/T,Western Union,MoneyGram
Supply Ability :
50 unit/month
Delivery Time :
20-30 working days
Packaging Details :
Wooden Case
Suitable Excavator(ton) :
25-35 ton
Impact Rate :
400-500 Bpm
Required Oil Flow :
170-200 l/min
Working Pressure :
110-140bar
Relief Pressure :
180-200 Bar
Operating Pressure :
130-150 Bar
Accumlator Pressure :
40 Bar
Tool Diameter :
135 MM
Hose Diameter :
1 Inch
Warranty :
1 Year
Description
Guchuan OEM Construction Mining MS700 Full Hydraulic System Breaker Hammer For Excavators
Construction And Mining Machinery Industry MS700 / GHB230/ GHB140 Box Type Excavator Hydraulic Breaker With Core Components Breaker Hammer Chisel
Product Overview
The MS700 hydraulic breaker is a heavy-duty construction machinery attachment designed for excavators and is suitable for a variety of engineering scenarios. It uses an efficient gas-oil impact system that can significantly increase the impact force while reducing the demand on the main hydraulic system. The device is equipped with a variety of chisel types (such as pointed, flat wedge, blunt and conical) to meet different operating needs. Its side-mounted design reduces the overall length and facilitates operation and maintenance.
OEM MS700 Full Hydraulic System Breaker Hammer For 25-35 Ton Excavators With 400-500 Bpm Impact Rate
Technical Specifications
Small Range Models
Model Applicable Weight (tons) Working Weight (kg) Impact Rate (bpm) Operating Pressure (bar) Chisel Diameter (mm)
SB10 0.8-2.5 73 800-1400 90-120 40
SB20 1.2-3 90 700-1200 90-120 45
SB30 2.5-4.5 120 600-1100 90-120 53
SB35 3-5.5 180 500-1000 100-130 60
SB40 4-7 298 500-900 110-140 68
SB43 6-9 380 400-800 120-150 75
R75 6-9 410 520-1000 110-130 75
SB45 7-14 510 400-800 130-160 85
SB50 11-16 890 350-700 150-170 100
SB60 15-18 1303 350-650 150-170 125
Medium Range Models
Model Applicable Weight (tons) Working Weight (kg) Impact Rate (bpm) Operating Pressure (bar) Chisel Diameter (mm)
HB15G 15-18 133 350-650 150-170 120
HB20G 18-25 1680 400-800 160-180 135
SB70 16-21 1544 350-600 160-180 135
NB500 18-26 1500 400-800 160-180 135
SB81 18-26 1830 350-500 160-180 140
Large Range Models
Model Applicable Weight (tons) Working Weight (kg) Impact Rate (bpm) Operating Pressure (bar) Chisel Diameter (mm)
HB30G 25-30 2305 350-700 160-180 150
SB121 28-35 2781 300-450 160-180 155
HB40G 35-43 2781 250-400 160-180 160
SB131 35-43 2996 250-400 160-180 165
SB151 40-50 3833 200-350 160-180 175
Application Fields
The MS700 / GHB230 hydraulic breaker is widely used in the following fields:
  • Mining: mining, rock crushing, secondary crushing
  • Infrastructure construction: tunnel excavation, roadbed compaction, and bridge demolition for railways and highways
  • Municipal engineering: concrete crushing, water, electricity, and gas engineering, and old urban area reconstruction
  • Building demolition: demolition of old buildings, crushing of reinforced concrete
  • Others: ice breaking, frozen soil crushing, and rust removal of hulls
OEM MS700 Full Hydraulic System Breaker Hammer For 25-35 Ton Excavators With 400-500 Bpm Impact Rate
Product Advantages
  • Efficient impact system: Adopts an efficient gas-oil impact system to increase the impact force while reducing the demand on the excavator's hydraulic system
  • Low maintenance cost: The design is simple, contains only two moving parts, and has low maintenance costs
  • Strong compatibility: Suitable for a variety of excavators, suitable for 25-35 tons of excavators
  • Shock and noise reduction: The shock-absorbing shell design is adopted to reduce noise and reduce the transmission of vibration to the host
  • Strong durability: High-quality steel and professional heat treatment technology are used to ensure the durability and stability of the equipment
  • Customized service: The appearance color, logo and brand can be customized according to customer needs
With its powerful functions and excellent performance, the MS700 / GHB230 hydraulic breaker has become an indispensable and efficient tool in the construction and mining fields.
Chisel Selection Guide
OEM MS700 Full Hydraulic System Breaker Hammer For 25-35 Ton Excavators With 400-500 Bpm Impact Rate
Product Structure
OEM MS700 Full Hydraulic System Breaker Hammer For 25-35 Ton Excavators With 400-500 Bpm Impact Rate
  • Through Bolt: Four bolts which connect the back head cylinder & front head
  • Back Head: The main function is to store nitrogen
  • Reversing Valve: Control the piston to move up and down at specified frequency
  • Cylinder: Here is the heart of the breaker, including the hydraulic circulation system to control the piston reciprocation
  • Piston: Transform the hydraulic power into strike power, punch the chisel to break
  • Front Head: The function is to support the cylinder and fix the chisel, to avoid the shaking force break the cylinder when operating
  • Chisel: Chisel is specially strengthened for wearing
Our Innovations
We can supply full hydraulic breakers of MB1500 and MSB250 for years. Currently we are developing new types hydraulic breakers and will come out in 2024.
Our Services
Pre-sale Services
  • Provide custom design service for client
  • Design and manufacture according to special requirement of client
  • Provide personnel technical training for clients
Medium-sales Service
  • Provide best forwarder option in cheap shipping seacost ahead of loading
  • Provide material/heat treatment/inspection report before loading
After-sales Services
  • Assist clients to prepare for the construction scheme
  • Provide install and debug equipment online service
  • Provide training for front-line workers from clients
OEM & ODM
We supply our GOOCHANCE brand hydraulic breakers, besides these, we also support OEM & ODM service.
Warranty
All our hydraulic breakers 12-18 months and spare parts 6 months.
Our Team
Team we have 4 girls to run and we can communicate in English/Japanese/Mexico smoothly.
Our Promise
We will be your reliable partner in construction machinery industry.
Frequently Asked Questions
Q: Are you a manufacturer?
A: Yes, our factory was established in 2010
Q: Are you sure your product will fit my excavator?
A: Our hydraulic breakers are suitable for most excavator. Show us your excavator model, we'll confirm the solution.
Q: How about your products warranty?
A: 12 months warranty for hydraulic breakers and 6 months for spare parts
Q: Can you produce according to customer's design?
A: Sure, OEM & ODM service available. We are professional manufacturer in Jiangsu.
Q: What's the MoQ and payment terms?
A: MOQ of hydraulic breaker is 1 set. Payment via T/T, Western Union accepted, our terms can be negotiated.
Q: How about delivery term?
A: 5-25 working days after payment
Q: How about the package?
A: Our hydraulic breakers wrapped by stretch film, packed by pallet or polywood case, or as requested
Q: Which country have you exported?
A: Saudi Arabia, Korea, Thailand, Cyprus, India, Canada, Australia, Peru, Egypt, Brazil, Mexico, South Africa, etc
