High-Capacity 1-10 Tons Per Hour Paper Baler with PLC Control and Safety Features for Efficient Recycling
High-Capacity 1-10 Tons Per Hour Paper Baler with PLC Control and Safety Features for Efficient Recycling
Specifications
Price :
negotiation
Balingcapacity :
1-10 tons per hour
Dimensions :
2000x1500x2500 mm
Bale weight :
100-1000 kg
Balesize :
Customizable, typically 500x500x700 mm
Bale size :
500x500x700 mm
Delivery Time :
20 working days
Safetyfeatures :
Emergency stop, safety guards, overload protection
Motorpower :
7.5-30 kW
Baling capacity :
1-10 tons per hour
Packaging Details :
wooden
Material :
Steel
Motor power :
7.5-30 kW
MOQ :
1
Baleweight :
100-1000 kg
Payment Terms :
T/T
Operatingvoltage :
380V/50Hz
Supply Ability :
30 set monthly
Controlsystem :
PLC control with automatic operation
Description
High-Capacity 1-10 Tons Per Hour Paper Baler with PLC Control and Safety Features for Efficient Recycling
  • The paper roll packaging blocks appear loose with insufficient density;
    • check the hydraulic oil level and oil quality;
    • increase the system pressure;
    • inspect the cylinder sealing rings for internal leakage;
    • and reduce the number of paper rolls loaded in a single cycle.
  • If paper rolls during feeding tend to deviate or roll,
    • inspect the anti-rolling limit device within the feed chamber;
    • ensure the paper rolls are positioned centrally;
    • and adjust the position of the feeding conveyor belt.
  • If the hydraulic cylinder does not operate,
    • first confirm that the emergency stop has been reset;
    • then check the power supply;
    • next, inspect the solenoid valve coil and valve core for any foreign debris;
    • finally, repair the travel limit switch.
  • Oil leakage fault:
    • Tighten the joint screws;
    • replace aged sealing rings and high-pressure oil pipes;
    • repair or replace the piston rod if scratched

    • Motor power

      90 kw

      Cycle time

      20 second

      Pressure

      25Mpa

      string Material

      5Wsicv

      Design system pressure

      25Mpa

      power source specification

      3PH380V

High-Capacity 1-10 Tons Per Hour Paper Baler with PLC Control and Safety Features for Efficient Recycling
