Fiber Compactor Hydraulic Waste Baler Machine With High Bale Density 500KG-650KG/M³
Fiber Compactor Hydraulic Waste Baler Machine With High Bale Density 500KG-650KG/M³
Specifications
Price :
negotiation
Packaging Details :
wooden box
Payment Terms :
T/T
Model Number :
HW 30T
Bale Density :
≥500KG-650KG/mз
Supply Ability :
30 set monthly
Delivery Time :
20 working days
Brand Name :
HUA WEI
Hydraulic oil type :
46# Anti-wear hydraulicoil
Place of Origin :
CHINA
MOQ :
1
Description

Fiber Compactor Baling Machine with High Bale Density 500KG-650KG/m³, 46# Anti-wear Hydraulic Oil for Waste Paper and Straw Compaction

Fiber Compactor
The Fiber Compactor is designed for efficient packing of loose materials in industrial waste management applications.

Universal hydraulic baling press machine with heavy-duty steel frame, designed for compressing various loose recyclable materials into dense bales. Equipped with reliable hydraulic system, it delivers stable compression force and long service life, widely used in recycling stations, manufacturing plants and waste management facilities.

Primary Applications
  • Waste paper edges and cardboard boxes
  • Carton edges and waste books
  • Magazines and printed materials
  • Straw and agricultural residues
  • Large waste paper processing
Interested in our industrial machinery solutions? Please contact us for detailed specifications and pricing information.

1 main oil cylinder pressure

300

2 Pressure

200T

3 Hydraulic system operating pressure

22MPA

4 Feed Opening size

1100*2200

5 Bale Size

W1100*H1250*( L can be adjustable )

6 Bale Density

≥500KG-650KG/mз

7 Baler line

Wire tie 30-3.6/3mm 4Line

8 Power system

High and low pressure combination of hydraulic system

9 Motor power

90 kw

10 Cycle time

20 second

11 Pressure

25Mpa

12 string Material

5Wsicv

13 Design system pressure

25Mpa

14 power source specification

3PH380V

15 Throughput

10-18 Tons/hour

16 Control system

PLC special probe automatic control system manual button control operating system

17 Hydraulic oil type

46# Anti-wear hydraulicoil

18 cooling system

water-cooling

19 Machine Weight

17T

20 Machine Overall Dimension L*W*H

9500mm*4500mm*3300mm

21 Hold tight control

Hydraulic automatic hold according to the system pressing requirements (PLC automatic control) pressing density

Fiber Compactor Hydraulic Waste Baler Machine With High Bale Density 500KG-650KG/M³
