For new machines operating for 150 hours, it is recommended to replace the hydraulic oil for the first time; thereafter, replace the hydraulic oil every 1,000–1,500 hours.

• Check the oil level daily for any oil leaks, and clean the oil tank's suction filter.
• It is prohibited to compress materials exceeding the specified tonnage limit; do not feed materials with a hardness exceeding the equipment's allowable limits.
• Regularly tighten wiring terminals and oil line connections; regularly inspect limit switches and safety doors.
• In low-temperature regions, select low-temperature anti-wear hydraulic oil for winter use; if necessary, activate oil heating.

• Key Features

  · Produces uniform, stackable bales for easy storage

  · Reduces waste handling and transportation costs

  · Robust construction for reliable daily operation

  · User-friendly control panel

  · Low energy consumption compared to larger systems

  Benefits

  Lower waste disposal cost, cleaner workplace, higher recycling revenue, compliance with environmental regulations.

• 1 main oil cylinder pressure	300
  2 Pressure	200T
  3 Hydraulic system operating pressure	22MPA
  4 Feed Opening size	1100*2200
  5 Bale Size	W1100*H1250*( L can be adjustable )
  6 Bale Density	≥500KG-650KG/mз
  7 Baler line	Wire tie 30-3.6/3mm 4Line
  8 Power system	High and low pressure combination of hydraulic system
  9 Motor power	90 kw
  10 Cycle time	20 second
  11 Pressure	25Mpa
  12 string Material	5Wsicv

•
