Fully Automatic Horizontal Baler PLC Control And 160T Pressure For Waste Paper Recycling
Fully Automatic Horizontal Baler PLC Control And 160T Pressure For Waste Paper Recycling
Specifications
Model Number :
HUAWEI 30T
Supply Ability :
30set monthly
Delivery Time :
20 working days
Price :
negotiation
Packaging Details :
wooden
Payment Terms :
T/T
Place of Origin :
CHINA
MOQ :
1
Brand Name :
HUAWEI
Description

Fully Automatic Horizontal Baler with PLC Control and 160T Pressure for Waste Paper Recycling

Horizontal Baler with Conveyor Feeding
Product Overview

Fully automatic hydraulic waste paper baler designed for efficient processing of loose materials in large waste paper recycling operations.

Key Features
  • Processes waste paper edges, cardboard boxes, carton edges, waste books, magazines, straw and similar materials
  • Automatic operation triggered by photoelectric switch when collection box is full
  • Unique anti-skid design for superior bundling effectiveness
  • Hydraulic system with differential technology reduces cycle time and improves efficiency
  • Automatic tension system ensures complete containment of all loose materials
  • Adjustable bundle length with bundle number accumulation function
  • International standard circuit layout with graphic operation instructions
  • Planer-processed press head for precise stamping operation
  • Low noise hydraulic circuit system combining imported and domestic components
  • PLC control for simplified circuits and reduced failure rates
  • Simple installation without foundation reinforcement requirements
  • Conveying line material, air pipe feeding and manual feeding operation options
Technical Specifications
Specification Value
Main Oil Cylinder Pressure 250
Pressure 160T
Hydraulic System Operating Pressure 20 MPA
Feed Opening Size 1080 × 2000 mm
Bale Size W1100 × H1250 × (L adjustable)
Bale Density ≥450 KG/m³
Baler Line Wire tie 2.6/3mm 4 Line
Power System High and low pressure combination hydraulic system
Motor Power 50.5 kW
Oil Pump Model VQ45
Pressure 20 Mpa
String Material 5Wsicv
Design System Pressure 25 Mpa
Power Source Specification 3PH 380V
Throughput 5-8 Tons/hour
Control System PLC special probe automatic control system with manual button control
Hydraulic Oil Type 46# Anti-wear hydraulic oil
Cooling System Water-cooling
Machine Weight 15 T
Machine Overall Dimension (L×W×H) 9000 × 4200 × 3000 mm
Bundling Method Automatic bundling
Hold Tight Control Hydraulic automatic hold according to system pressing requirements (PLC automatic control)
