Product Overview

Technical Specifications

• Material Number: 1834486001
• Brand: Rexroth
• Operating Voltage: 24 VDC (external power supply required)
• Environmental Temperature: -20°C to +70°C
• Protection Rating: IP20 (protection against dust and indirect contact)
• Installation Type: Screw mounting or top-hat rail installation
• Mechanical Fixing: Screw mounting or top-hat rail installation, with optional vertical mounting adapter for some models
• Electrical Connection: Screw terminals for reliable connection of signal and power lines
• Card Locking: Card lock design with ejection function for easy insertion and removal of boards
• Weight: 0.5 kg
• Dimensions:
  • Width: 63 mm
  • Height: 40 mm

Features

• High Precision: Ensures accurate control and monitoring of hydraulic systems.
• Robust Design: Suitable for industrial environments with high reliability.
• Versatile Applications: Suitable for a wide range of industrial automation applications.
• Easy Installation: Designed for easy integration into existing systems.
• 32-Pin Socket Connector: Form D, DIN 41612
• Current Rating: 4A
• Connection Cross-Section: Insertion screw terminals with a maximum of 4 mm²

Applications

• Servo Drive Systems: Used for base function testing and signal expansion of dual-axis servo drives (e.g., HMD01.1N-W0020-A-07-NNNN).
• Proportional Valve Control: Suitable for precise regulation of hydraulic valves with proportional amplifiers (e.g., VT-VSPD-1-2X/V0).
• Automation Production Lines: Supports PLC integration and bus communication (e.g., EtherCAT, PROFINET) to enhance system response speed.
