A4VSO250DR 30R-PPB13N00 Mechanical Hydraulic Pump Variable Displacement Axial Piston Pump From Bosch Rexroth
A4VSO250DR 30R-PPB13N00 Mechanical Hydraulic Pump Variable Displacement Axial Piston Pump From Bosch Rexroth
A4VSO250DR 30R-PPB13N00 Mechanical Hydraulic Pump Variable Displacement Axial Piston Pump From Bosch Rexroth
A4VSO250DR 30R-PPB13N00 Mechanical Hydraulic Pump Variable Displacement Axial Piston Pump From Bosch Rexroth
A4VSO250DR 30R-PPB13N00 Mechanical Hydraulic Pump Variable Displacement Axial Piston Pump From Bosch Rexroth
A4VSO250DR 30R-PPB13N00 Mechanical Hydraulic Pump Variable Displacement Axial Piston Pump From Bosch Rexroth
A4VSO250DR 30R-PPB13N00 Mechanical Hydraulic Pump Variable Displacement Axial Piston Pump From Bosch Rexroth
A4VSO250DR 30R-PPB13N00 Mechanical Hydraulic Pump Variable Displacement Axial Piston Pump From Bosch Rexroth
A4VSO250DR 30R-PPB13N00 Mechanical Hydraulic Pump Variable Displacement Axial Piston Pump From Bosch Rexroth
A4VSO250DR 30R-PPB13N00 Mechanical Hydraulic Pump Variable Displacement Axial Piston Pump From Bosch Rexroth
Specifications
Brand Name :
Rexroth
Model Number :
A4VSO250LR2G 30RPPB13N00
Certification :
cc
Place of Origin :
Germany
MOQ :
1
Price :
RMB/100-10000/PC
Payment Terms :
T/T
Supply Ability :
10PCS/days
Delivery Time :
3 work days
Packaging Details :
wooden case/carton
Material :
Cast Iron
Local Service Location :
None
Shipping Date :
Within 3 Days After Payment
Payment :
TT
Standard Or Nonstandard :
standard
Description
Rexroth Hydraulic Pump A4VSO250DR 30R-PPB13N00
Product Specifications
Attribute Value
Material Cast Iron
Shipping Date Within 3 Days After Payment
Payment TT
Standard Standard
The A4VSO250DR 30R-PPB13N00 is a high-performance variable displacement axial piston pump from Bosch Rexroth, designed for industrial hydraulic applications. Below are its detailed specifications and features:

Technical Specifications

  • Model: A4VSO250DR 30R-PPB13N00
  • Series: A4VSO
  • Type: Variable displacement axial piston pump
  • Displacement Range: Up to 250 cm³
  • Nominal Pressure: 350 bar
  • Maximum Pressure: 400 bar
  • Speed Range: Up to 2200 RPM
  • Flow Rate: Variable, depending on displacement and speed
  • Control Type: Pressure control
  • Direction of Rotation: Clockwise (R)
  • Body Material: Cast Iron
  • Seal Type: Viton or NBR
  • Fluid Compatibility: Mineral oil, synthetic hydraulic oil (viscosity range 15–160 mm²/s)
  • Working Temperature Range: -25°C to +90°C (-13°F to +195°F)
  • Weight: Approximately 187.9 kg

Features

  • Variable Displacement: Allows for adjustable flow rates to meet specific system requirements.
  • High Pressure Capability: Suitable for high-pressure applications up to 400 bar.
  • Robust Design: Ensures long service life and durability.
  • Low Noise Level: Designed for low noise operation, making it suitable for noise-sensitive environments.
  • Excellent Suction Characteristics: Ensures stable performance during oil suction.
  • Modular Design: Allows for easy integration into various hydraulic systems.
  • Short Response Times: Ensures quick and precise control.
  • Optional Mounting Position: Flexible installation options.
  • Visual Swivel Angle Indicator: Provides easy monitoring of the pump's operating state.

Applications

The A4VSO250DR 30R-PPB13N00 is suitable for a variety of industrial applications, including:
  • Engineering & Construction Machinery: Ideal for hydraulic drives in heavy machinery.
  • Metallurgical Industry: Suitable for hydraulic stations in rolling mills.
  • Plastic Injection Molding Machines: High-pressure control for mold clamping units.
  • Construction Machinery: Hydraulic drive systems in excavators and cranes.
  • Ceramic and Refractory Presses: High-pressure applications in material processing.
This pump is designed to enhance system efficiency, reduce downtime, and provide reliable performance in demanding industrial environments.
A4VSO250DR 30R-PPB13N00 Mechanical Hydraulic Pump Variable Displacement Axial Piston Pump From Bosch Rexroth
Frequently Asked Questions
Do you accept small orders?
Yes, we accept small orders. Please contact us for details.
Can you ship to my country?
Yes, we can arrange shipping worldwide. We can assist with logistics if needed.
What are your payment terms?
We accept T/T, LC at sight, or 100% full payment.
What is your production lead time?
Typically 15 days for MOQ quantities, depending on product and order size.
When can I get a quotation?
We provide quotes within 24 hours of inquiry. Urgent requests can be prioritized.
