Product Description:

The Pelton Hydro Turbine is a highly efficient and robust solution designed for harnessing hydro energy in high-head water sources. Renowned for its exceptional performance in converting the kinetic energy of water into mechanical energy, this turbine is ideal for a wide range of hydroelectric power generation projects. Whether utilized in small-scale installations or large power plants, the Pelton Hydro Turbine delivers reliable and consistent energy output, making it a preferred choice among engineers and energy producers worldwide.

One of the defining characteristics of the Pelton Hydro Turbine is its runner type, which can be configured as either a single-jet or multi-jet runner. This flexibility allows the turbine to be tailored to specific site conditions and project requirements. The single-jet runner is typically used in scenarios with moderate flow rates and high water heads, while the multi-jet runner is designed to handle larger flow volumes, increasing power output and efficiency. This adaptability ensures that the turbine can efficiently operate across a broad range of applications, from remote micro-hydro setups to large-scale hydroelectric facilities.

The Pelton Hydro Turbine excels in environments with a water head ranging from 100 meters to 800 meters, making it particularly suitable for high-head sites where water pressure is substantial. Its design head is optimized between 200 meters and 600 meters, ensuring peak operational efficiency within this range. This capability to operate effectively under high water heads classifies the Pelton Hydro Turbine as a High-Pressure Turbine, specifically engineered to withstand and exploit the intense energy found in elevated water sources.

With a rated speed of 750 revolutions per minute, the Pelton Hydro Turbine balances rotational speed and torque to maximize energy conversion. This rated speed is carefully selected to synchronize with the electrical generators commonly used in hydroelectric power plants, optimizing the overall system performance. The turbine’s power capacity spans from 1 MW to 200 MW, accommodating a vast spectrum of power generation needs. From small community-based hydro projects producing minimal power to large industrial-scale plants generating hundreds of megawatts, the Pelton Hydro Turbine delivers consistent, scalable performance.

Unlike other types of turbines that rely on pressure changes within the water flow, the Pelton Hydro Turbine operates as an impulse turbine. This distinguishes it from reaction hydro turbines, which involve energy extraction through a combination of pressure and velocity changes inside the turbine runner. The Pelton Hydro Turbine’s operation is based purely on the impulse of water jets striking the turbine’s buckets, making it exceptionally suitable for sites with high water heads and relatively low flow rates. This characteristic allows it to achieve high efficiency and durability under conditions where reaction hydro turbines may not perform optimally.

As a Hydro Jet Turbine, the Pelton Hydro Turbine harnesses the energy from high-velocity water jets. Water is directed through nozzles at high pressure, creating focused jets that impact the specially designed bucket-shaped runner. This interaction transforms the water’s kinetic energy into mechanical energy, which is then converted into electrical energy by the connected generator. The precision engineering of the nozzles and runner buckets ensures minimal energy loss and maximum transfer efficiency, making the Pelton Hydro Turbine a top choice in hydroelectric power technology.

In summary, the Pelton Hydro Turbine stands out as a premier solution for high-head hydroelectric power generation. Its ability to operate effectively across a wide range of water heads, combined with its flexible runner configurations and substantial power capacity, makes it uniquely capable of meeting diverse energy needs. As a High-Pressure Turbine and a Hydro Jet Turbine, it offers advantages in efficiency, durability, and adaptability. Furthermore, by distinguishing itself from reaction hydro turbines through its impulse-driven mechanism, the Pelton Hydro Turbine continues to be a cornerstone technology in the advancement of sustainable and renewable energy production worldwide.

Features:

• Product Name: Pelton Hydro Turbine
• Nozzle Ring made of Stainless Steel 0Cr13Ni4Mo (CA6NM) for enhanced durability
• Rated Speed: 750r/min ensuring optimal performance
• Power Capacity ranging from 1 MW to 200 MW to suit various energy needs
• Design Head between 200m and 600m for efficient energy conversion
• Bucket Design: Double Cup or Split Bucket options available
• Operates as a Water Impulse Turbine, utilizing high head water flow
• Incorporates the Pelton Water Wheel design for maximum hydraulic efficiency
• Though primarily an impulse turbine, complements Axial-Flow Turbine systems in hydropower setups

Technical Parameters:

Applications:

The Wawushan Pelton Hydro Turbine, model number CJA-2025, is a high-performance impulse turbine designed for efficient energy generation in various hydroelectric power applications. Manufactured in China and certified with ISO9001, this turbine combines advanced engineering with reliable quality assurance. Its bucket design, featuring double cup or split bucket options, ensures optimal water flow management, making it ideal for high-pressure turbine requirements where maximizing energy conversion is critical.

With a rated speed of 750r/min and a power capacity ranging from 1 to 200 MW, the Pelton Hydro Turbine is well-suited for a wide range of power generation projects, from small-scale installations to large hydroelectric plants. The product is especially effective in scenarios where water source conditions involve high head and low flow, typical for impulse turbines. Its design complements axial-flow turbine systems by providing a specialized solution for high-pressure turbine applications, ensuring that energy extraction from high-velocity water jets is maximized.

This turbine is commonly applied in mountainous regions where rivers have steep gradients, enabling efficient conversion of potential energy into mechanical energy. It is also widely used in remote power generation projects that require reliable and sustainable energy sources. The Pelton Hydro Turbine’s robust construction and precision bucket design make it ideal for continuous operation under demanding conditions, such as those found in high-pressure turbine environments.

Packaging is done using standard methods to ensure safe delivery, with a delivery time of approximately 6 months. The minimum order quantity is one unit, and the supply ability stands at 100 sets per unit time, making it accessible for both individual projects and large-scale deployments. Payment terms are flexible, typically conducted via L/C, which facilitates smooth international transactions.

Overall, the Wawushan Pelton Hydro Turbine is a versatile and reliable choice for applications that require a high-pressure turbine solution, especially when integrated with axial-flow turbine systems. Its advanced bucket design and impulse turbine technology provide efficient energy conversion, making it a preferred option for hydroelectric power plants aiming to optimize their high-pressure turbine installations.

Customization:

The Wawushan Pelton Hydro Turbine, model number CJA-2025, is a high-quality Water Jet Turbine designed for efficient energy generation. Originating from China and certified with ISO9001, this High-Pressure Turbine is engineered to operate with a water head range of 50-1000 meters, and a power capacity between 1 to 200 MW, making it suitable for various hydroelectric projects.

Featuring a stainless steel 0Cr13Ni4Mo (CA6NM) nozzle ring, the turbine ensures durability and optimal performance under high-pressure water jets. The Pelton Hydro Turbine operates with a low noise level, enhancing environmental compatibility.

Wawushan offers customization services with a minimum order quantity of 1 set, priced at $50,000 per unit. The packaging is standard, and delivery time is approximately 6 months. Payment terms are flexible, primarily L/C, with a supply ability of 100 sets per unit time.

This Water Jet Turbine is an excellent choice for projects requiring reliable, efficient, and customizable High-Pressure Turbines to harness hydro power effectively.

Support and Services:

Our Pelton Hydro Turbine product is supported by a dedicated team of technical experts committed to ensuring optimal performance and longevity of your turbine installation. We offer comprehensive technical support services including installation guidance, operational training, maintenance procedures, troubleshooting assistance, and performance optimization.

Our service package includes detailed product documentation, remote diagnostics, and periodic inspections to help detect and resolve issues proactively. We also provide customized training sessions for your operational staff to enhance their understanding of the turbine’s mechanics and control systems.

In addition, our engineering team is available to assist with any upgrades, retrofits, or modifications to adapt your Pelton Hydro Turbine to changing operational requirements or to improve efficiency.

With our commitment to quality and customer satisfaction, we strive to deliver timely and effective support to maximize the value and reliability of your Pelton Hydro Turbine investment.
